ADM1060
TABLE 27. LIST OF REGISTERS FOR THE PROGRAMMABLE LOGIC BLOCK ARRAY (PLBA) (Contd.)
Hex
Table
Name
Address
19
29
P2PLBIMKB
1 A
30
P2SFDPOLB
1 B
31
P2SFDIMKB
20
28
P3PLBPOLA
21
29
P3PLBIMKA
22
30
P3SFDPOLA
23
31
P3SFDIMKA
24
32
P3GPIPOL
25
33
P3GPIIMK
26
34
P3WDICFG
27
35
P S 3 E N
28
28
P3PLBPOLB
29
29
P3PLBIMKB
2 A
30
P3SFDPOLB
2 B
31
P3SFDIMKB
30
28
P4PLBPOLA
31
29
P4PLBIMKA
32
30
P4SFDPOLA
33
31
P4SFDIMKA
34
32
P4GPIPOL
35
33
P4GPIIMK
36
34
P4WDICFG
37
35
P S 4 E N
PRELIMINARY TECHNICAL DATA
Default
Power On Value
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
Description
Ignore Mask for all 8 other PLB outputs when used as
inputs to the B function of PLB2
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB2
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB2
Polarity Sense for all 8 other PLB outputs when used as
inputs to the A function of PLB3
Ignore Mask for all 8 other PLB outputs when used as
inputs to the A function of PLB3
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB3
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB3
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the A function of PLB3
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the B function of PLB3
Polarity Sense and Ignore Mask bits for the pulsed and
latched outputs of the watchdog detector when used as
inputs to both A and B functions of PLB3
Enable bits for A and B functions of PLB3, polarity bit
for PLB3 output
Polarity Sense for all 8 other PLB outputs when used as
inputs to the B function of PLB3
Ignore Mask for all 8 other PLB outputs when used as
inputs to the B function of PLB3
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB3
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB3
Polarity Sense for all 8 other PLB outputs when used as
inputs to the A function of PLB1
Ignore Mask for all 8 other PLB outputs when used as
inputs to the A function of PLB1
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB1
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB1
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the A function of PLB1
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the B function of PLB1
Polarity Sense and Ignore Mask bits for the pulsed and
latched outputs of the watchdog detector when used as
inputs to both A and B functions of PLB4
Enable bits for A and B functions of PLB4, polarity bit
for PLB4 output
–20–
ADM1060 LOGIC
REV. PrJ 11/02
