ADM1060 LOGIC
TABLE 27. LIST OF REGISTERS FOR THE PROGRAMMABLE LOGIC BLOCK ARRAY (PLBA) (Contd.)
Hex
Table
Name
Address
75
33
P8GPIIMK
76
34
P8WDICFG
77
35
P S 8 E N
78
28
P8PLBPOLB
79
29
P8PLBIMKB
7 A
30
P8SFDPOLB
7 B
31
P8SFDIMKB
80
28
P9PLBPOLA
81
29
P9PLBIMKA
82
30
P9SFDPOLA
83
31
P9SFDIMKA
84
32
P9GPIPOL
85
33
P9GPIIMK
86
34
P9WDICFG
87
35
P S 9 E N
88
28
P9PLBPOLB
89
29
P9PLBIMKB
8 A
30
P9SFDPOLB
8 B
31
P9SFDIMKB
REV. PrJ 11/02
PRELIMINARY TECHNICAL DATA
Default
Power On Value
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
Description
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the B function of PLB8
Polarity Sense and Ignore Mask bits for the pulsed and
latched outputs of the watchdog detector when used as
inputs to both A and B functions of PLB8
Enable bits for A and B functions of PLB8, polarity bit
for PLB8 output
Polarity Sense for all 8 other PLB outputs when used as
inputs to the B function of PLB8
Ignore Mask for all 8 other PLB outputs when used as
inputs to the B function of PLB8
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB8
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB8
Polarity Sense for all 8 other PLB outputs when used as
inputs to the A function of PLB9
Ignore Mask for all 8 other PLB outputs when used as
inputs to the A function of PLB9
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB9
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB9
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the A function of PLB9
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the B function of PLB9
Polarity Sense and Ignore Mask bits for the pulsed and
latched outputs of the watchdog detector when used as
inputs to both A and B functions of PLB9
Enable bits for A and B functions of PLB9, polarity bit
for PLB9 output
Polarity Sense for all 8 other PLB outputs when used as
inputs to the B function of PLB9
Ignore Mask for all 8 other PLB outputs when used as
inputs to the B function of PLB9
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB9
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB9
–23–
ADM1060
