ADM1060
TABLE 33. BIT MAP FOR PNGPIIMK REGISTERS (POWER- ON DEFAULT 00H)
Bit
7-4 AIMK4-AIMK1
3-0 BIMK4-BIMK1
7 Function A
6
5
4
3 Function B
2
1
0
TABLE 34. PnWDICFG REGISTERS 06H,16H,26H,36H,46H,56H,66H,76H,86H (POWER- ON DEFAULT 00H)
Bit
7
6
5
4
3
2
1
0
TABLE 35. PnEN REGISTERS 07H,17H,27H,37H,47H,57H,67H,77H,87H (POWER- ON DEFAULT 00H)
Bit
7-3
2
1
0
PRELIMINARY TECHNICAL DATA
Name R/W Description
R / W If high, mask the GPIn input before it is used in function A
R / W If high, mask the GPIn input before it is used in function B
PLB1
05H
GPI1
GPI2
GPI3
GPI4
GPI1
GPI2
GPI3
GPI4
Name R/W Description
A P O L P R / W If high, invert the pulsed WDI input before it is used in function A
A I M K P R / W If high, mask the pulsed WDI input before it is used in function A
APOLL R / W If high, invert the latched WDI input before it is used in function A
A I M K L R / W If high, mask the latched WDI input before it is used in function A
B P O L P R / W If high, invert the pulsed WDI input before it is used in function B
B I M K P R / W If high, mask the pulsed WDI input before it is used in function B
B P O L L R / W If high, invert the latched WDI input before it is used in function B
B I M K L R / W If high, mask the latched WDI input before it is used in function B
Name R/W Description
Reserved N/A Cannot be used
I N V O P R / W If high, invert the PLB output
ENA R / W If high, enable function A
ENB R / W If high, enable function B
PLB2 PLB3 PLB4
15H 25H 35H
GPI1 GPI1 GPI1
GPI2 GPI2 GPI2
GPI3 GPI3 GPI3
GPI4 GPI4 GPI4
GPI1 GPI1 GPI1
GPI2 GPI2 GPI2
GPI3 GPI3 GPI3
GPI4 GPI4 GPI4
–26–
ADM1060 LOGIC
PLB5 PLB6 PLB7
45H 55H 65H
GPI1 GPI1 GPI1
GPI2 GPI2 GPI2
GPI3 GPI3 GPI3
GPI4 GPI4 GPI4
GPI1 GPI1 GPI1
GPI2 GPI2 GPI2
GPI3 GPI3 GPI3
GPI4 GPI4 GPI4
PLB8 PLB9
75H 85H
GPI1 GPI1
GPI2 GPI2
GPI3 GPI3
GPI4 GPI4
GPI1 GPI1
GPI2 GPI2
GPI3 GPI3
GPI4 GPI4
REV. PrJ 11/02
