ADM1060 LOGIC
TABLE 27. LIST OF REGISTERS FOR THE PROGRAMMABLE LOGIC BLOCK ARRAY (PLBA) (Contd.)
Hex
Table
Name
Address
38
28
P4PLBPOLB
39
29
P4PLBIMKB
3 A
30
P4SFDPOLB
3 B
31
P4SFDIMKB
40
28
P5PLBPOLA
41
29
P5PLBIMKA
42
30
P5SFDPOLA
43
31
P5SFDIMKA
44
32
P5GPIPOL
45
33
P5GPIIMK
46
34
P5WDICFG
47
35
P S 5 E N
48
28
P5PLBPOLB
49
29
P5PLBIMKB
4 A
30
P5SFDPOLB
4 B
31
P5SFDIMKB
50
28
P6PLBPOLA
51
29
P6PLBIMKA
52
30
P6SFDPOLA
53
31
P6SFDIMKA
54
32
P6GPIPOL
55
33
P6GPIIMK
when
Hex
Table
Name
Address
REV. PrJ 11/02
PRELIMINARY TECHNICAL DATA
Default
Power On Value
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
Default
Power On Value
Description
Polarity Sense for all 8 other PLB outputs when used as
inputs to the B function of PLB4
Ignore Mask for all 8 other PLB outputs when used as
inputs to the B function of PLB4
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB4
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB4
Polarity Sense for all 8 other PLB outputs when used as
inputs to the A function of PLB5
Ignore Mask for all 8 other PLB outputs when used as
inputs to the A function of PLB5
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB5
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB5
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the A function of PLB5
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the B function of PLB5
Polarity Sense and Ignore Mask bits for the pulsed and
latched outputs of the watchdog detector when used as
inputs to both A and B functions of PLB5
Enable bits for A and B functions of PLB5, polarity bit
for PLB5 output
Polarity Sense for all 8 other PLB outputs when used as
inputs to the B function of PLB5
Ignore Mask for all 8 other PLB outputs when used as
inputs to the B function of PLB5
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB5
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB5
Polarity Sense for all 8 other PLB outputs when used as
inputs to the A function of PLB6
Ignore Mask for all 8 other PLB outputs when used as
inputs to the A function of PLB6
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB6
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB6
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the A function of PLB6
Polarity Sense and Ignore Mask bits for all 4 GPI's
Description
–21–
ADM1060
used as inputs to the B function of PLB6
