ADM1060 LOGIC

PLBA REGISTER NAMES

TABLE 27. LIST OF REGISTERS FOR THE PROGRAMMABLE LOGIC BLOCK ARRAY (PLBA)
Hex Table Name
Address
00 28 P1PLBPOLA
01 29 P1PLBIMKA
02 30 P1SFDPOLA
03 31 P1SFDIMKA
04 32 P1GPIPOL
05 33 P1GPIIMK
06 34 P1WDICFG
07 35 P S 1 E N
08 28 P1PLBPOLB
09 29 P1PLBIMKB
0 A 30 P1SFDPOLB
0 B 31 P1SFDIMKB
10 28 P2PLBPOLA
11 29 P2PLBIMKA
12 30 P2SFDPOLA
13 31 P2SFDIMKA
14 32 P2GPIPOL
15 33 P2GPIIMK
16 34 P2WDICFG
17 35 P S 2 E N
18 28 P2PLBPOLB
REV. PrJ 11/02
PRELIMINARY TECHNICAL DATA
Default
Power On Value
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
Description
Polarity Sense for all 8 other PLB outputs when used as
inputs to the A function of PLB1
Ignore Mask for all 8 other PLB outputs when used as
inputs to the A function of PLB1
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB1
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB1
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the A function of PLB1
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the B function of PLB1
Polarity Sense and Ignore Mask bits for the pulsed and
latched outputs of the watchdog detector when used as
inputs to both A and B functions of PLB1
Enable bits for A and B functions of PLB1, polarity bit
for PLB1 output
Polarity Sense for all 8 other PLB outputs when used as
inputs to the B function of PLB1
Ignore Mask for all 8 other PLB outputs when used as
inputs to the B function of PLB1
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB1
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB1
Polarity Sense for all 8 other PLB outputs when used as
inputs to the A function of PLB2
Ignore Mask for all 8 other PLB outputs when used as
inputs to the A function of PLB2
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB2
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB2
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the A function of PLB2
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the B function of PLB2
Polarity Sense and Ignore Mask bits for the pulsed and
latched outputs of the watchdog detector when used as
inputs to both A and B functions of PLB2
Enable bits for A and B functions of PLB2, polarity bit
for PLB2 output
Polarity Sense for all 8 other PLB outputs when used as
inputs to the B function of PLB2
