ADM1060 INPUTS
POSITIVE VOLTAGE SUPPLY FAULT DETECT (PSNSFD) REGISTERS
TABLE 13. REGISTER B8H,C0H,C8H,D0H
Bit
Name
7-0
OV7-OV0
TABLE 14. REGISTER B9H,C1H,C9H,D1H PSnOVHYST (POWER- ON DEFAULT 00H)
Bit
Name
7-5
Reserved
4-0
HY4-HY0
TABLE 15. REGISTER BAH,C2H,CAH,D2H
Bit
Name
7-0
UV7-UV0
TABLE 16. REGISTER BBH,C3H,CBH,D3H PSnUVHYST (POWER- ON DEFAULT 00H)
Bit
Name
7-5
Reserved
4-0
HY4-HY0
TABLE 17. REGISTER BCH,C4H,CCH,D4H
Bit
Name
7
Reserved
6-4
GF2-GF0
3-2
RSEL1-RESL0
1-0
FS1-FS0
REV. PrJ 11/02
PRELIMINARY TECHNICAL DATA
PSNOVTH (POWER- ON DEFAULT FFH)
R/W
R / W
R/W
N/A
R / W
PSnUVTH (POWER- ON DEFAULT 00H)
W
R / W
W
N/A
R / W
PSnSEL (POWER- ON DEFAULT 00H)
R/W
N/A
R / W
R / W
R / W
Description
8 bit digital value for overvoltage threshold on PSn SFD.
Description
Cannot be used
5 bit digital value for hysteresis on OV threshold of PSn SFD
Description
8 bit digital value for undervoltage threshold on PSn SFD
Description
Cannot be used
5 bit digital value for hysteresis on UV threshold of PSn SFD
Description
Cannot be used
GF2
GF1
GF0
0
0
0
0
0
1
0
1
0
0
1
1
1
0
0
1
0
1
1
1
0
1
1
1
RSEL1
RSEL0
Bottom of
Range
0
0
2 V
0
1
1 V
1
X
0.6V
FS1
FS0
Fault Select Type
0
0
Overvoltage
0
1
Undervoltage
1
0
Out-of-Window
1
1
Not Allowed
–13–
ADM1060
Glitch Filter Delay ( s)
0
5
10
20
30
50
75
100
Top of
Step Size (mV)
Range
6 V
15.6
3 V
7.8
1.8V
4.7
