Revision History
Rev. H
1. Update of specs. pages
2. Inclusion of Table of Contents
3. Inclusion of EEPROM download at Power- Up (p.38)
2Rev. G
1. Update of specs. pages (better definition of supply conditions, inclusion of input impedance, better definition of PDO
output conditions).
2. Removal of PUEN (pull-up current source on logic inputs) function (See Rev. F-7).
Rev. F
1. Update of specs. to reflect 14V drive capability of charge pumped outputs.
2. Correction of features on bipolar SFD's- only 1 range available in negative mode.
3. Better definition of SFD Glitch Filter
4. Completion of register map- addition of table numbers for each register, addition of register map matrix (p.43)
5. Improved definition of all ADM1060 blocks.
6. Definition of fault/status reporting on the ADM1060
7. Addition of Pull- Up/Down current source on logic inputs
8. Corrected version of how SMBus protocol is implemented on the ADM1060.
9. Inclusion of device ID registers (p.37)
REV. PrJ 11/02
PRELIMINARY TECHNICAL DATA
OUTLINE DIMENSIONS
Dimensions shown in inches and (mm)
28- Lead TSSOP (RU-28)
0.386 (9.80)
0.378 (9.60)
28
1
PIN 1
0.006 (0.15)
0.002 (0.05)
0.0118 (0.30)
0.0256 (0.65)
SEATING
0.0075 (0.19)
BSC
PLANE
15
14
0.0433
(1.10)
o
MAX
8
0.028 (0.70)
o
0.020 (0.50)
0
0.0079 (0.20)
0.0035 (0.090)
–45–
ADM1060
