TABLE 2. LIST OF REGISTERS FOR THE SUPPLY FAULT DETECTORS (Contd.)
Hex
Table
Name
Address
C 2
15
PS2UVTH
C 3
16
PS2UVHYST
C 4
17
PS2SEL
C 8
13
PS3OVTH
C 9
14
PS3OVHYST
C A
15
PS3UVTH
C B
16
PS3UVHYST
C C
17
PS3SEL
D 0
13
PS4OVTH
D 1
14
PS4OVHYST
D 2
15
PS4UVTH
D 3
16
PS4UVHYST
D 4
17
PS4SEL
PRELIMINARY TECHNICAL DATA
Default
Power On Value
00h
00h
00h
FFh
00h
00h
00h
00h
FFh
00h
00h
00h
00h
Description
Undervoltage Threshold for PS2SFD
Digital Hysteresis on UV threshold for PS2SFD
Glitch filter, Range and Fault Type select for PS2SFD
Overvoltage Threshold for Positive Voltage SFD3 (PS3SFD)
Digital Hysteresis on OV threshold for PS3SFD
Undervoltage Threshold for PS3SFD
Digital Hysteresis on UV threshold for PS3SFD
Glitch filter, Range and Fault Type select for PS3SFD
Overvoltage Threshold for Positive Voltage SFD4 (PS4SFD)
Digital Hysteresis on OV threshold for PS4SFD
Undervoltage Threshold for PS4SFD
Digital Hysteresis on UV threshold for PS4SFD
Glitch filter, Range and Fault Type select for PS4SFD
–10–
