ADM1060 STATUS/FAULTS

MASK REGISTERS

TABLE 50. LIST OF MASK REGISTERS
Hex Table
Addr.
9 D 51
9E 52
TABLE 51. BIT MAP FOR ERRMASK1 REGISTER 9DH (POWER- ON DEFAULT 00H)
Bit Name
7 Reserved
6 V P 4 M A S K
5 V P 3 M A S K
4 V P 2 M A S K
3 V P 1 M A S K
2 V H M A S K
1 V B 2 M A S K
0 V B 1 M A S K
TABLE 52. BIT MAP FOR ERRMASK2 REGISTER 9EH (POWER- ON DEFAULT 00H)
Bit Name
7-5 Reserved
4 W D I M A S K
3 GPI4MASK
2 GPI3MASK
1 GPI2MASK
0 GPI1MASK
REV. PrJ 11/02
PRELIMINARY TECHNICAL DATA
Name Default
Power On Value
ERRMASK1 00h
ERRMASK2 00h
R/W Description
X Unused
R / W If high, then a fault occurring on the supply at input VP4 is ignored, and not logged in LATF1
R / W If high, then a fault occurring on the supply at input VP3 is ignored, and not logged in LATF1
R / W If high, then a fault occurring on the supply at input VP2 is ignored, and not logged in LATF1
R / W If high, then a fault occurring on the supply at input VP1 is ignored, and not logged in LATF1
R / W If high, then a fault occurring on the supply at input VH is ignored, and not logged in LATF1
R / W If high, then a fault occurring on the supply at input VB2 is ignored, and not logged in LATF1
R / W If high, then a fault occurring on the supply at input VB1 is ignored, and not logged in LATF1
R/W Description
X Unused
R / W If high, then a change in the logic level on the WDI output is ignored, and not logged in LATF2
R / W If high, then a change in the logic level on the GPI4 input is ignored, and not logged in LATF2
R / W If high, then a change in the logic level on the GPI3 input is ignored, and not logged in LATF2
R / W If high, then a change in the logic level on the GPI2 input is ignored, and not logged in LATF2
R / W If high, then a change in the logic level on the GPI1 input is ignored, and not logged in LATF2
Description
Error Mask Register for the 7 SFD's
Error Mask Register for the 4 GPI's and the Watchdog Detector
–35–
ADM1060
