ADM1060 STATUS/FAULTS
TABLE 43. BIT MAP FOR SFDSTAT REGISTER DAH (POWER- ON DEFAULT 00H)
Bit
7
6
5
4
3
2
1
0
TABLE 44. BIT MAP FOR GWSTAT REGISTER DBH (POWER- ON DEFAULT 00H)
Bit
7-5
4
3
2
1
0
TABLE 45. BIT MAP FOR PDOSTAT1 REGISTER DEH (POWER- ON DEFAULT 00H)
Bit
7
6
5
4
3
2
1
0
TABLE 46. BIT MAP FOR PDOSTAT2 REGISTER DFH (POWER- ON DEFAULT 00H)
Bit
7-1
0
REV. PrJ 11/02
PRELIMINARY TECHNICAL DATA
Name R/W
Reserved N/A
VP4FLT R
VP3FLT R
VP2FLT R
VP1FLT R
VHFLT R
VB2FLT R
VB1FLT R
Name R/W
Reserved N/A
WDISTAT R
GPI4STAT R
GPI3STAT R
GPI2STAT R
GPI1STAT R
Name R/W
PDO8STAT R
PDO7STAT R
PDO6STAT R
PDO5STAT R
PDO4STAT R
PDO3STAT R
PDO2STAT R
PDO1STAT R
Name R/W
Reserved N/A
PDO9STAT R
Description
Cannot be used
If high, then fault (UV, OV or Out- of- Window) has occurred on VP4 input
If high, then fault (UV, OV or Out- of- Window) has occurred on VP3 input
If high, then fault (UV, OV or Out- of- Window) has occurred on VP2 input
If high, then fault (UV, OV or Out- of- Window) has occurred on VP1 input
If high, then fault (UV, OV or Out- of- Window) has occurred on VH input
If high, then fault (UV, OV or Out- of- Window) has occurred on VB2 input
If high, then fault (UV, OV or Out- of- Window) has occurred on VB1 input
Description
Cannot be used
If high, then timeout has elapsed on the Watchdog Detector
Logic level currently being driven on GPI4 input
Logic level currently being driven on GPI3 input
Logic level currently being driven on GPI2 input
Logic level currently being driven on GPI1 input
Description
Logic level currently being driven on PDO8 output
Logic level currently being driven on PDO7 output
Logic level currently being driven on PDO6 output
Logic level currently being driven on PDO5 output
Logic level currently being driven on PDO4 output
Logic level currently being driven on PDO3 output
Logic level currently being driven on PDO2 output
Logic level currently being driven on PDO1 output
Description
Cannot be used
Logic level currently being driven on PDO9 output
