ADM1060
TABLE 27. LIST OF REGISTERS FOR THE PROGRAMMABLE LOGIC BLOCK ARRAY (PLBA) (Contd.)
Hex
Table
Name
Address
56
34
P6WDICFG
57
35
P S 6 E N
58
28
P6PLBPOLB
59
29
P6PLBIMKB
5 A
30
P6SFDPOLB
5 B
31
P6SFDIMKB
60
28
P7PLBPOLA
61
29
P7PLBIMKA
62
30
P7SFDPOLA
63
31
P7SFDIMKA
64
32
P7GPIPOL
65
33
P7GPIIMK
66
34
P7WDICFG
67
35
P S 7 E N
68
28
P7PLBPOLB
69
29
P7PLBIMKB
6 A
30
P7SFDPOLB
6 B
31
P7SFDIMKB
70
28
P8PLBPOLA
71
29
P8PLBIMKA
72
30
P8SFDPOLA
73
31
P8SFDIMKA
74
32
P8GPIPOL
PRELIMINARY TECHNICAL DATA
Default
Power On Value
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
Description
Polarity Sense and Ignore Mask bits for the pulsed and
latched outputs of the watchdog detector when used as
inputs to both A and B functions of PLB6
Enable bits for A and B functions of PLB6, polarity bit
for PLB6 output
Polarity Sense for all 8 other PLB outputs when used as
inputs to the B function of PLB6
Ignore Mask for all 8 other PLB outputs when used as
inputs to the B function of PLB6
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB6
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB6
Polarity Sense for all 8 other PLB outputs when used as
inputs to the A function of PLB7
Ignore Mask for all 8 other PLB outputs when used as
inputs to the A function of PLB7
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB7
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB7
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the A function of PLB7
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the B function of PLB7
Polarity Sense and Ignore Mask bits for the pulsed and
latched outputs of the watchdog detector when used as
inputs to both A and B functions of PLB7
Enable bits for A and B functions of PLB7, polarity bit
for PLB7 output
Polarity Sense for all 8 other PLB outputs when used as
inputs to the B function of PLB7
Ignore Mask for all 8 other PLB outputs when used as
inputs to the B function of PLB7
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB7
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the B function of PLB7
Polarity Sense for all 8 other PLB outputs when used as
inputs to the A function of PLB8
Ignore Mask for all 8 other PLB outputs when used as
inputs to the A function of PLB8
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB8
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP's) to
the A function of PLB8
Polarity Sense and Ignore Mask bits for all 4 GPI's when
used as inputs to the A function of PLB8
–22–
ADM1060 LOGIC
REV. PrJ 11/02
