Chapter 11

Specifications

11.1 Introduction

The following sections detail the specifications for the Transpector MPH Gas
Analysis System. As a result of INFICON continuing product improvement and
quality assurance programs, these specifications are subject to change without
notice or obligation.
NOTE: All specifications are measured after a 30 minute warm-up period at

11.2 Sensor Length (Vacuum Side)

MPH100F
143 mm
(5.63 in.)

11.3 Mass Range

MPH100F

11.4 Detector Type

MPH100F
Faraday Cup
11 - 1
constant STP unless specified.
MPH100M
193 mm
(7.82 in.)
MPH100M
1 to 100 AMU
MPH100M
Continuous Faraday Cup
Dynode
Electron
Multiplier /
Faraday Cup
MPH200F MPH200M
143 mm 193 mm
(5.63 in.) (7.82 in.)
MPH200F MPH200M
1 to 200 AMU
MPH200F MPH200M
Continuous
Dynode
Electron
Multiplier /
Faraday Cup
Transpector MPH Operating Manual
MPH300F MPH300M
143 mm 193 mm
(5.63 in.) (7.82 in.)
MPH300F MPH300M
1 to 300 AMU
MPH300F MPH300M
Faraday Cup Continuous
Dynode
Electron
Multiplier /
Faraday Cup
