1 - 13
CAUTION
Maximum bakeout temperature for sensors is shown in
Table 1-1.
Table 1-1 Sensor maximum bakeout temperature
Sensor
MPH100F/200F/300F
MPH100M/200M/300M
CAUTION
The Transpector MPH electronics module must be
removed prior to bakeout at temperatures greater than
200°C (FC).
Do not turn on the Electron Multiplier (EM) at sensor
temperatures above 150°C. Turning on the EM at elevated
temperature could result in permanent damage to the
detector.
WARNING
During or immediately after bakeout, the heating jacket
and metal surfaces in the vicinity of the heating jacket
may be extremely hot. These surfaces may exceed 100°C
at the maximum ambient operating temperature (50°C),
which will cause burns if touched directly without using
the proper personal protection equipment.
Transpector MPH Operating Manual
Maximum Maximum Bakeout
Operating
Temperature Electronics Removed
200°C
150°C
Temperature
300°C
300°C
