1.16.1.1 ConFlat Flanges

The sensor is installed on a vacuum system with a 2.75 in. DN40 ConFlat flange.
ConFlat flanges, and similar compatible types made by other manufacturers, are
used for attaching devices to ports on high vacuum systems. If there are no
concerns with the installation of this type of flange, proceed to
Attaching the Sensor to the Vacuum Chamber, on page
NOTE: If the system does not have a port with a compatible mating flange, an
To install these flanges without leaks, follow proper operating procedures. These
flanges are sealed with a metal gasket and can be heated for bakeout to
temperatures of up to 300°C. For bakeout temperatures when a sensor is installed,
see Table 1-1 on page

1.16.1.1.1 Assembling ConFlat Flanges

To assemble a pair of ConFlat flanges:
1
Wipe the sealing areas of the flanges with a laboratory towel using a clean
solvent, such as water free alcohol. These areas must be clean and free of
particulate matter.
2
Install the copper gasket between the two flanges. (See
use a new gasket. Do not attempt to use gaskets more than once.
Figure 1-3 Gasket and flange assembly
adapter will be necessary.
1-13.
CAUTION
Do not touch the gasket and flange faces with your
fingers during the installation process.
Transpector MPH Operating Manual
section 1.16.1.2,
1-11.
Figure
Flange
Copper Gasket
Flange
1-3.) Always
1 - 10
