Connecting To Transpector Web Ui With A User-Defined Ip Address; Navigating Transpector Web Ui; Status - Inficon Transpector MPH Operating Manual

5.3.2 Connecting to Transpector Web UI with a User-Defined IP Address

If the IP address has been changed from the default factory IP address, the new
user-defined IP address must be entered into the browser. If the IP address was
changed and the new address has been lost, contact INFICON.

5.4 Navigating Transpector Web UI

Transpector Web UI functionality is split between several different windows.
To navigate from window to window, click on the button of the desired window.
The buttons are displayed in
Figure 5-3 Transpector Web UI window selection buttons
The first window displayed by Transpector Web UI is STATUS. In the following
sections, the different windows are identified and described.
For information on using the different windows, continue to
Transpector Web UI, on page

5.4.1 STATUS

The STATUS window, see
several parameters.
Figure 5-4 STATUS window
5 - 5
Figure 5-3.
5-10.
Figure 5-4, provides information regarding
Transpector MPH Operating Manual
section 5.5, Using
