HYDRAULIC SYSTEM

PRESSURE SETTING PROCEDURES

The following procedures should be used to properly check,
adjust and set the hydraulic system pressures.
The following equipment is required for checking the
hydraulic pressure settings.
• Pressure Gauge
• Three dial gauge 0-345 bar (0-5000 psi)
• Diagnostic quick disconnect - Grove P/N 9999101806
and straight adapter fitting 7447040401
Table 2-2
Valve Pressure Setting Table
Valve To Be Set
Hoist(s), and Lift Pressure Setting
Telescope Extend Pressure
Telescope Retract Pressure
Outrigger Extend/Retract and Swing Left/
Right Pressure Setting
Air Conditioning Circuit Relief Valve
Pressure
Steer Pressure Setting
Swing Brake Supply Pressure Setting
Pilot Supply Pressure Setting
Counterweight Removal Extend/Retract
and Cab Tilt Relief Pressure Setting
2-24
Reservoir Oil Temperature to be Approximately 49°C (120°F
Pressure
Setting
bar (PSI)
276 (4000)
179 (2600)
239 (3460)
214 (1500)
103 (2000)
150 (2175)
18 - 20
(260 - 300)
28 - 31
(400 - 450)
172 (2500)
Published 01-29-2014, Control # 496-00
TMS800E SERVICE MANUAL
• ORFS reducers as required to attach work port hoses to
the gauge.
NOTE: When checking the directional control valve relief
settings, unless otherwise specified, start with the
engine at idle RPM and move the controller to its
fully stroked position. Then slowly accelerate the
engine to the specified RPM. Read gauge and
make adjustments to specified setting.
When checking the outrigger relief valve setting,
start with the engine at idle RPM and activate and
hold the extend or retract switch. Then slowly
accelerate the engine to the specified RPM. Read
gauge and make adjustment as required.
Tolerance Gauge Port (GPX) and Adjustment
bar (PSI)
± 4 (50) GP2 Superstructure mounted
accessory manifold with swing
directional control valve (see
Figure 2-14)
± 4 (50) GP5 Superstructure mounted main
directional control valve port relief
valve (see Figure 2-15)
± 4 (50) GP5 Superstructure mounted main
directional control valve port relief
valve (see Figure 2-15)
± 4 (50) GP7 Carrier mounted outrigger control
manifold (see Figure 2-18)
± 4 (50) GP Carrier mounted flow control
manifold (see Figure 2-17)
± 4 (50) GP8 Carrier mounted Priority Flow
Pump Relief (see Figure 2-19)
See Range GP4 Superstructure mounted
accessory manifold with swing
directional control valve (see
Figure 2-14)
See Range GP3 Superstructure mounted
accessory manifold with swing
directional control valve (see
Figure 2-14)
± 4 (50) GP2 Superstructure mounted
accessory manifold with swing
directional control valve (see
Figure 2-14)
Location
