LUBRICATION
42. Lower Boom Nose Sheaves
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months, whichever occurs
first
Lube Amount - Until grease extrudes
Application - 4 grease fittings per sheave
43. Jib Sheaves
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months, whichever occurs
first
Lube Amount - Until grease extrudes
Application - 2 grease fittings
44. Jib Mast Sheave
Lube Type - EP-MPG
Lube Interval - 500 hours or 12 months, whichever
occurs first
Lube Amount - Until grease extrudes
Application - 1 grease fitting
45. Auxiliary Boom Nose Sheave
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months, whichever
interval occurs first
Lube Amount - Until grease extrudes
Application - 1 grease fitting
46. Hook Block Swivel Bearing
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months, whichever
interval occurs first
Lube Amount - Until grease extrudes
Application - 1 grease fitting
9-12
47. Hook Block Sheaves
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months, whichever
interval occurs first
Lube Amount - Until grease extrudes
Application - 1 grease fitting per sheave
(4 fittings total - 75 ton)
48. Overhaul Ball Swivel Top
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months, whichever
interval occurs first
Lube Amount - Until grease extrudes
Application - 1 grease fitting
49. Turntable Swivel Lock Pin
Lube Type - OGL
Lube Interval - 500 hours or 6 months, whichever
interval occurs first
Lube Amount - Coat points requiring periodic lubrication
Application - Spray on

WIRE ROPE LUBRICATION

Wire rope is lubricated during manufacturing so that the
strands, and individual wires in strands, may move as the
rope moves and bends. A wire rope cannot be lubricated
sufficiently during manufacture to last its entire life.
Therefore, new lubricant must be added periodically
throughout the life of a rope to replace factory lubricant which
is used or lost.
NOTE:
For more detailed information concerning the lubrication and
inspection of wire rope, refer to Wire Rope, page 1-17.
Published 01-29-2014, Control # 496-00
TMS800E SERVICE MANUAL
Wire rope may be purchased by contacting the
Manitowoc Crane Care Parts Department.
