TMS800E SERVICE MANUAL
CAUTION
When installing cylinder retaining pin, orient it so that
when cotter pins are installed they will be horizontal.
5. Lower the jack until the holes in the cylinder rod align
with the holes in the tube. Apply Never-Seeze to the
retaining pin. Secure the cylinder and cylinder cap
bracket in place with the retaining pin and cotter pins.
6. Install the hydraulic lines as tagged prior to removal.
7. Install the cylinder tube cap.
8. Position the float pad on the cylinder ball and secure
with capscrews, washers, locknuts, and bushings.
Tighten locknut until the washer just touches the pad. Do
not tighten any further. Torque capscrews 97.6 to 105.7
Nm (72 to 78 lb-ft).
9. Position the tilt plate on the mounting bracket and
secure with the capscrews, washers, flatwashers, and
nuts. Torque capscrews 40.6 to 43.3 Nm (30 to 32 lb-ft).
GROVE
Functional Check
Extend and set the four main outriggers before extending
the center front stabilizer.
1. Extend and set the outriggers.
2. Activate the hydraulic system; extend and retract the
outrigger.
3. Observe for proper operation of the cylinder.
4. Check the hydraulic connections for evidence of
leakage.
When installing cylinder retaining pin, orient it so that
when cotter pins are installed they will be horizontal.
Published 01-29-2014, Control # 496-00
