TMS800E SERVICE MANUAL
Table 3-5
Amp Crimping Tool Table
Description
14 to 12 gauge wire
10 to 8 gauge wire
4 to 9 circuit
(in-line connectors
15
(in-line connectors
Table 3-6
Deutsch Extraction Tool Table
Description
12 gauge wire
16 gauge wire
8-10 gauge wire
4-6 gauge wire
Table 3-7
Deutsch Crimping Tool Table
Description
12, 14, 16, 18, 20 gauge wire
4, 6, 8, 10 gauge wire
GROVE
Amp Part Number
Tool Die
69710-1 90145-1
69710-1 90140-1
69710-1 90306-1
90299-1 --
Deutsch Part Number
114010
0411-204-1605
114008
114009
Deutsch Part Number
HDT-48-00
HDT04-08
Published 01-29-2014, Control # 496-00
ELECTRIC SYSTEM
Grove Part Number
Tool
9-999-100177
9-999-100177 9-999-100178
9-999-100177
N/A
Grove Part Number
9-999-100194
9-999-100195
7-902-000012
7-902-000009
Grove Part Number
9-999-100808
9-999-100842
Die
N/A
N/A
--
3
3-11
