TMS800E SERVICE MANUAL
2
3
8
6
6979
Item
1 Reservoir
2 Return Filter
3 Return Manifold Inlet
4 Sight Gauge (Oil Level Gauge)
GROVE
7
1
Description
Published 01-29-2014, Control # 496-00
5
4
Item
5 Access Cover
6 Filler Cap
7 Drain Plug (Not Shown)
8 Thermometer
HYDRAULIC SYSTEM
9
FIGURE 2-3
Description
2-9
