HYDRAULIC SYSTEM

PRESSURE SETTING PROCEDURES

The following procedures should be used to properly check,
adjust and set the hydraulic system pressures.
The following equipment is required for checking the
hydraulic pressure settings.
• Three dial pressure gauge, 0-5000 psi
• Pressure check diagnostic quick disconnect - Grove P/N
9999101806 and straight adapter fitting 7447040401
• ORFS reducers as required to attach work port hoses to
the gauge.
Table 2-3
Valve Pressure Setting Table
Valve To Be Set
NOTE: Reservoir oil temperature to be approximately 100° F (38° C)
Outrigger/Rear Steer/Axle Lockout
Pressure
Outrigger Beam Extend Pressure
Piston Pump # 1 Differential Pressure
(Delta P)
Piston Pump # 2 Differential Pressure
(Delta P)
Steer Pressure Setting
Control Pressure
Main Hoist Raise Pressure
Main Hoist Lower Pressure
Auxiliary Hoist Raise Pressure
Auxiliary Hoist Lower Pressure
Telescope Pressure Setting
Telescope Pinning Pressure
Lift Raise Pressure
2-22
NOTE:
Pressure
Tolerance
Setting
PSI (bar)
PSI (bar)
3000 (33.1) ± 50 (0.4)
2000 (138) ± 50 (0.4)
350 (24) ± 25 (0.2)
375 (26) ± 25 (0.2)
2500 (172) ± 50 (0.4)
508 (35) ± 25 (0.2)
4351 (300) ± 50 (0.4)
1740 (120) ± 50 (0.4)
4351 (300) +50 (0.4)
1740 (120) ± 50 (0.4)
2901 (200) ± 50 (0.4)
1450 (100) +25 (0.2)
4351 (300) ± 50 (0.4)
Published 1-16-2017 Control # 343-07
RT9150E SERVICE MANUAL
When checking the directional control valve relief
settings, unless otherwise specified, start with the
engine at idle RPM and move the controller to its
fully stroked position. Then slowly accelerate the
engine to the specified RPM. Read gauge and
make adjustments to specified setting.
The number after G (gauge port) corresponds to
the gauge port number on the hydraulic system
schematic (G1 through G3).
All valve settings can be obtained by adjusting the
valve "in" to increase or "out" to decrease the
pressure accordingly.
Gauge Port (GPX) and Adjustment
Location (MCV - Main Control Valve)
(CCV - Compact Control Valve
G - Carrier mounted outrigger/rear
steer control manifold (Figure 2-11)
G - Carrier mounted outrigger/rear
steer control manifold (Figure 2-11)
G1 - Carrier mounted outrigger/rear
steer control manifold (Figure 2-10)
and (Figure 2-11)
G1 - Carrier mounted outrigger/rear
steer control manifold (Figure 2-10)
and (Figure 2-11)
GPS Superstructure mounted
accessory manifold (Figure 2-25)
MSt Adjust at DM MCV (Figure 2-22)
MA3 MCV Adjust at D3 MCV
(Figure 2-15) and (Figure 2-17)
MB3 MCV Adjust at D6
MCV(Figure 2-15) and (Figure 2-17)
MA1 on MCV control valve. Adjust at
D1 on the auxiliary hoist control valve
(Figure 2-15) and (Figure 2-17)
MB1 on MCV Adjust at D4 on the
auxiliary hoist control valve
(Figure 2-15) and (Figure 2-17)
MB2 MCV. Adjust at D2 on MCV
(Figure 2-17)
MA6 on MCV Adjust at DBV (telescope
locking) (Figure 2-20)
MA1 MCV. Adjust at D1on MCV
(Figure 2-15)
