TMS800E SERVICE MANUAL
Leak Detection
If a leak is suspected, shut off the engine and note the air
pressure reading of both circuits. Acceptable air pressure
6
1
5
4
4 7
Item Description
1 Air Reservoir
2 Pressure Protection Valve
3 Air Reservoir
4 Air Dryer
5 Front Service Brake Relay Valve
6 Tire Suspension Solenoid Valve
GROVE
8
7
2
Published 01-29-2014, Control # 496-00
loss is 0.40 bar (6 psi) within 30 minutes. A hard to detect
leak can be found by wetting the suspected area with a soap
solution and observing for bubbles.
11
3
1
View B-B
Item Description
7 Supply Dump Valve
8 Air Suspension Valve
9 Spring Brake Relay Valve
10 Rear Service Brake Relay Valve
11 Inter-Axle Differential Lock Solenoid Valve
12 Cross Axle Differential Lock Valve (Optional)
13 Tractor Protection Valve (Optional)
UNDERCARRIAGE
10
12
9
13
13
FIGURE 8-65
8-47
8
