UNDERCARRIAGE
2
1
10
11
Item
1 Retainer Clip
2 Boot
3 Clevis Pin
4 Actuator Rod
5 Retaining Ring
6 Roller Pin
7 Actuator Piston
8 Adjusting Sleeve
9 Retainer Clip
10 Clevis
11 Clevis Pin
8-40
3
4
7
6
5
9
8
13
15
22
23
Description
Published 01-29-2014, Control # 496-00
12
14
21
Item
12 Housing
13 Bushing
14 Gasket
15 Pull Pawl Assembly
16 Worm Gear
17 Manual Adjusting Nut
18 Retaining Ring
19 Worm Grease Seal
20 Grease Fitting
21 Face Seal
22 Gear
23 Retainer/Seal
TMS800E SERVICE MANUAL
16
18
20
6600
FIGURE 8-51
Description
17
19
