Item
29 Turntable Gearbox
30 Turntable Gear and Drive Pinion
31 Turntable Bearing
32 Main Hoist
33 Auxiliary Hoist
34 Boom Pivot Shaft
35 Extend Cable Sheaves
36 Retract Cable Sheaves
37 Telescope Cylinder Wear Pads
Internal Side and Bottom Wear Pads (Internal
38
Sections)
39 Boom Section Upper Wear Pads
40 Boom Section Upper and Lower Wear Pads
41 Upper Boom Nose Sheaves
42 Lower Boom Nose Sheaves
43 Jib Sheaves
44 Jib Mast Sheave
45 Auxiliary Boom Nose Sheave
46 Hook Block Swivel Bearing
47 Hook Block Sheaves
48 Overall Ball Swivel Top
49 Turntable Swivel Lock Pin
