TMS800E SERVICE MANUAL
7
8
Item
1 Turntable
2 Accessory Manifold with Swing Directional Valve
3 Pilot Operated Check Valve (Cab Tilt)
Counterweight Removal/Cab Tilt Directional
4
Control Valve
5 Hoist/Telescope/Lift Directional Control Valve\
6 Outrigger Selector Valve
GROVE
5
2
SUPERSTRUCTURE
Description
Published 01-29-2014, Control # 496-00
6
CARRIER
4
3
1
Item
7 Motor Control Manifold
8 Charge Oil Cooler Control Manifold
9 Rear Outrigger Control Manifold
10 Front Outrigger Control Manifold
HYDRAULIC SYSTEM
9
10
6550-5
6551
FIGURE 2-13
Description
