HYDRAULIC SYSTEM
Item
1 Main Hoist Directional Valve
2 Auxiliary Hoist Directional Valve
3 Telescope Directional Valve
4 Lift Directional Valve
5 Thermal Relief Valve
6 Pilot Drain Port (PD)
7 Telescope Extend Relief Valve
8 Inlet Port (P2)
9 Load Sense Input Port (LS)
10 Telescope Retract Relief Valve
11 Load Sense Relief
2-36
Description
Published 01-29-2014, Control # 496-00
TMS800E SERVICE MANUAL
Item Description
12 Load Sense Outlet (Not Shown)
13 Inlet Port (P1) (Not Shown)
14 Main Hoist Up (A Port)
15 Main Hoist Down (B Port)
16 Auxiliary Hoist Up (A Port)
17 Auxiliary Hoist Down (B Port)
18 Telescope Out (A Port)
19 Telescope In (B Port)
20 Lift Up (A Port)
21 Lift Down (B Port)
22 Gage Port (GP)
