TMS800E SERVICE MANUAL
Item Description
7 Engine Exhaust Tube
8 Square Cap
9 Muffler Clamp
10 Capscrew
11 Lock Washer
12 Hex Nut
13 Wide Flat Washer
14 Flat Washer
15 Muffler Clamp
16 Not Used
17 Retaining Nut
18 Exhaust Wrap
19 T-Bolt Clamp
20 Capscrew
21 Flat Washer
22 Lock Washer
23 Hex Nut
100 Muffler Mount
101 Muffler Guard
102 Muffler Support
103 Exhaust Cover
104 Muffler Cover
105 Bracket
106 Cover
GROVE

Installation

1. Install muffler mounting bands on muffler mount
2. Install muffler to mounting bands.
3. Install exhaust connector assembly.
4. As needed, install a replacement exhaust wrap around
the exhaust tube.
5. Install muffler cover to exhaust cover.
6. Install exhaust stack on muffler. Secure exhaust stack
with clamp.
7. Install muffler guard to muffler mount.
ISX ENGINE DIESEL PARTICULATE FILTER/
SELECTIVE CATALYST REDUCTION
ASSEMBLY

Removal

Do not touch muffler or exhaust parts until they are at
ambient temperature. Severe burning may result.
1. Remove capscrews, lockwashers, flat washers, and
nuts to all guards and covers.
2. Loosen the V-Band clamps to free the DPF from the
exhaust tube and 90° elbow. Note the location of each
clamp and gasket.
3. Remove hardware securing mounting bands to DPF and
remove DPF assembly.
4. Loosen the V-Band clamp between the adapter tube and
SCR. Note the location of each clamp and gasket.
5. Remove hardware securing mounting bands to the SCR
and using an appropriate lifting device remove the SCR.
Published 01-29-2014, Control # 496-00
POWER TRAIN
CAUTION
7
7-19
