2. Pull the speaker into the computer to remove it (2).
To install the speaker, reverse the removal procedures.

System board

To remove the system board, use these procedures.
NOTE: All system board spare part kits include replacement thermal material.
Before removing the system board, follow these steps:
1. Prepare the computer for disassembly (see
2. Remove the access panel (see
3. Remove the fan (see
4. Remove the heat sink (see
5. Remove the processor (see
6. Remove the memory modules (see
7. Remove the riser assembly (see
8. Remove the solid-state drive (see
9. Remove the WLAN module (see
10. Remove the RTC battery (see
11. Remove the power button (see
12. Remove the speaker (see
Remove the system board:
1. Remove the Torx screw from the USB bracket (1), and then remove the bracket (2).
Access panel on page
Fan on page 18).
Heat sink on page
Processor on page
Memory modules on page
Riser assembly and expansion cards on page
Solid-state drive on page
WLAN module on page
Battery on page
Power button on page
Speaker on page 34).
Preparation for disassembly on page
17).
19).
21).
22).
28).
29).
32).
33).
17).
25).
System board 35
