6.3. Electrical specifications
6.3.1 . Linear Axis Controller
Operating supply voltage
Quiescent power (minimum
Warning
The linear axis controller is CE marked and cCSAus certified. Any modification will void the certification.
The following Palletizing Control Box diagram shows roughly how the connections are made. For more information, download the
electrical package on the Robotiq support website . Do not modify wiring unless you can re-certify the control box with local authorities.
Specifications
power consumption)
Peak current
Fig. 6-5: Linear Axis Controller electrical specifications
Value
100-240 Vac
60/50 Hz
290 Wmax
205 Wrms
12.8A at 120Vac
6.4A at 240Vac
Palletizing Solution - Instruction Manual
79
