4. Operation
⑬Order Point Off (Option)
OrdOff : Order Point Off
When there are more than 2 cavity products in the mold, each cavity part can be released
different position with Order Point Off Option.
Default setting is "NoUse". If "Use" , Number of Cavity is " 2 "
OrdOff
NoUse
Pitch
Number
Order Point Off ( Pitch x Number ) should be lower than Multi Point Off's pitch
In order release (off) mode, if (Pitch×Cycle) is larger than multi release (off)
This is optional feature, Please contact factory.
54 TSα Series User Manual
◀
0mm
1
mode pitch, it displays "(Pitch×Cycle) should be set with 0000.
Kick
Up/Down
Cycle
Travers
3
2
Main Arm Release Position
Pitch
1
