⑫ Multi Point Off
MulOff: Multi Point Off
Each cycle can release ( Off ) part in a different location ( Position ) with specified distance
with Multi Point Off Function. Default setting is "NoUse". If "USE" , Default number of point is
" 1 ".
MulOff NoUse
Pitch 0mm
Cycle 1
( Pitch × Number of Cycle ) should be in the distance of ( Products
Release( Off ) position – Descent available location )
In multi release (Off) mode, if (Pitch×cycle) is larger than (Release Position-
Arm Descent Range) it displays "(Pitch×cycle) should be set with 0000, press
C key will cancel input number.
◀ 1Cycle
2Cycle
3Cycle
Kick
Traverse
Up/Down
3
Cycle
Main Arm Release Position
TSα Series User Manual 53
4. Operation
Pitch
1
2
