3
Figure 3-2 PS-ATS
Front Panel: Upright
Position
3-4
Initial Power-Up Tests

Common Control Power Supply Test

...................................................................................................
PS-ATS Power-Up Verification
The PS-ATS units, see Figure
independent from each other. One unit is sufficient to power the entire control shelf.
There is no test to verify the power output.
1. Forcibly push each PS-ATS unit back into its slot. See
page 7-19
for more information on the PS-ATS units.
2. The technician must only verify that the green POWER indicator on each
PS-ATS front panel is illuminated and that the red FAIL indicator is off after
power is applied to the Control Shelf.
3. Fasten the four captive screws on each corner of each PS-ATS to secure it into
place.
3-2, installed on the control shelf are completely
PS-ATS
POWER
FAIL
Coral FlexiCom 6000 Installation Manual
PS-ATS beginning on
