Figure 3-1 Power Input Terminals - Tadiran Telecom Coral FlexiCom 6000 Installation Procedure And Hardware Reference Manual

Hide thumbs
Table of Contents

Advertisement

Figure 3-1
Power Input
Terminals
Coral FlexiCom 6000 Installation Manual
Ground Cable
Entry Clamp
GND
48V
RTN
SGND
Power Cable
Entry Clamp
FUSE
30A / 60V
F1
F2
SPARE FUSE
PIC
(Power Input Card)
-48V
IN
6000
Power Input Cover
Decorative Panel
Pull to Remove
3-3
Initial Power-Up Tests
