Table 8-6 VGA
Interface Pin Functions
8-32
Common Control Cards
Pin # Signal Mnemonic
1 RED
2 GREEN
3 BLUE
4 NC
5 DACVSS
6 DACVSS
7 DACVSS
8 DACVSS
9 NC
10 DACVSS
11 NC
12 DDCDAT
13 HSYNC
14 VSYNC
15 DDCCLK
Function
Red signal
Green signal
Blue signal
no connection
Video return
Video return
Video return
Video return
no connection
Video return
no connection
Display Data Channel data signal for DDC2 support
Horizontal synchronization
Vertical synchronization
Display Data Channel clock signal for DDC2 support
