4-28
Software Installation Procedure
Diagnostic Tests
The PI test options can be obtained from the Root, 1, 0 branch. See Chapter 22 of the
relevant Program Interface and Data Reference Manual for further details. Selecting
a test not relevant for the Coral FlexiCom 6000 systems, results in the following
message:
ERROR, Not Available on ATS, Try Again
Faulty Object Alarms
Alarms are transmitted to the PI from the various relevant parts of the system. The
Coral's Faulty Object Alarms menu Root, 0, 1, 1 contains many categories, only the
items relevant to the Coral FlexiCom 6000 systems are listed below:
Faulty Objects PI Alarm Text and
Alarms Description
6-PCM HW
HIGHWAY# FAILURE DATE/TIME
Details the failed PCM highway# and date and time of
fault.
7-PCM LINKS
HIGHWAY# TIME SLOT# T/R
T = Transmit/ R = Receive
Details the failed PCM highway#, as well as the failed
time slot# and date and time of fault
8-PB AND
PB# FAULT SHELF#
POWER SUPPLY
PB# Removed SHELF#
SHELF# PPS
SHELF# RPS
Details the faulty PB-ATS (1 or 2) and its system shelf#.
Details whether a PB-ATS was removed from service,
and from which shelf.
Details the faulty PPS or RPS and its respective
peripheral shelf#.
Note: Shelf #'s range from 0 to 15, but only even
numbered shelves house PB-ATS units.
Major
or
Minor
Alarm
Major
Minor
Major
