Coral FlexiCom 6000 Installation Manual
Jumper settings
The CLA-ATS includes a number of jumpers that are factory set, defined by the
manufacturer. The jumper settings should not be changed in anyway. The technician
must only verify that Jumper W4 is connected with a shorting plug. A list of the
jumper settings is provided below, however, the jumper configurations may differ
from card to card.
Jumper
W1-CPU Core Voltage- 1.6V
when On
W2- Remote Reset
W4 - Onboard Battery
W6- VT100/Download Mode
W7- Onboard Video
W9, W10 COM2 Terminations
W11- Compact Flash
J7 - Fan Header
Coral Configuration
1-2 On
3-4 Off
5-6 On
7-8 Off
9-10 On
Disabled- Off
Connected- On
Normal Mode - Off
Enabled - Off
RS-422/485 modes only
Without Termination resistors - off
Slave - Off
Off
8-83
Common Control Cards
