Coral FlexiCom 6000 Installation Manual

Switching between System Sides

...................................................................................................
The Active side may be on the left or right side of the Control Shelf, as displayed in
the above table. All updates to the HSB system must be performed from the Active
side. This may be easily determined by viewing the screen of Root Menu on the PI
Terminal. The PI states which system side it is monitoring by displaying either
ACTIVE, STANDBY, MAINTENANCE or FAULTY. The physical Active system
side is readily viewed from the 32GC card front panel indicators for Active, Standby,
Faulty or Maintenance, see
be viewed from the HSB branch of the PI.
Determining the Physical Active System Side:
1. From either PI terminal of the HSB system, access the HSB branch by typing
HSB from anywhere in the PI or enter 0,11 from the Root Menu.
2. The PI prompts:
0-Update
1-Display
Enter 1 to display the parameters and their current values.
3. The PI immediately displays all the parameters describing the HSB setup.
Table 4-4 includes a list of all the PI parameters for the HSB branch with a
short description of each parameter.
4. View the following read-only parameter,
CONTROL (0,1) -
If the value for Control is 0 , the current Active side is located on the right side
of the Control Shelf. If the value is 1 , it is located on the left side.
The full list of HSB PI parameters is presented in
Parameter Name Range
HSB Yes/No
Read-Only
OTHER MCP Yes/No
Read-Only
EXISTS
32GC Front Panel on page
Table 4-4
Description
Displays whether this is a Hot Standby system
(Yes) or single control system (No).
If this displays No, then the following parameters
are not displayed.
Displays whether the MCP-ATS is installed on the
other system side.
8-62. This information can also
below.
Software Installation Procedure
4-15
