Card Description - Tadiran Telecom Coral FlexiCom 6000 Installation Procedure And Hardware Reference Manual

2
8-82
Common Control Cards
Additionally, if a CLA-ATS card fails the CTI application will fail and will not invoke
a control changeover.

Card Description

...................................................................................................
Card Front Panel
The CLA-ATS front panel, depicted in
Video - RS-232 adapter - for connecting a video terminal to set the card BIOS.

Reset button - causes the CLA-ATS to drop all CTI calls and resets the card.

The card automatically reestablishes a network connection.
IDE Indicator

Power indicator - Green - indicates that the CLA card is active and properly

working when lit.
COM1 Connection- NOT USED

Network Interface- Ethernet/LAN RJ-45 connection

Keyboard/Mouse connector - for connecting a keyboard to set card BIOS.

Ready to Swap Indicator

Card Layout
An ATA type PCMCIA port to house the CFD is located on the card side, see
Figure 8-28.
The 64MB (or more) Compact Flash memory Disk (CFD) contains the card's software
and programming code.
The CLA-ATS card also contains an NMI/watchdog circuit, providing a reset signal
to the Core Module should it detect a failure in the software cycle.
Figure 8-27 contains the following items:
