Coral FlexiCom 6000 Installation Manual
Component
ST
HS
PWR/Alarm
HDD
Function
Status LED is a green/red bi-color for BIOS
l
power-up status indication, after boot loading
the user software is free to use this LED for
it's own purpose.
• Red on - Power-up, still Reset state
(also the HS blue LED is on)
• Blink red 1Hz - BIOS early init
• Blink amber 1Hz - BIOS start POST
• Blink green 1Hz up to 4Hz - BIOS
POSTA init
• Green on - OS boot
• Red on - System halted or reset
Hot Swap (blue), working according the hot
l
swap specification.
Power (green)/Alarm (red)
l l
Hard Disk Drive (green) indicates hard drive
l l
activity on the primary IDE channel.
Caution: Do not remove the card from its slot
when this LED is flashing.
Removing a Control Card, page
See
8-12.
8-31
Common Control Cards
