Coral FlexiCom 6000 Installation Manual

Verifying the BIOS Settings

...................................................................................................
The Coral system arrives at the site ready to use. However, in the event that the system
fails to complete the start-up cycle, it is possible to enter the MCP-ATS BIOS and
verify that the settings are correct by using a temporarily attached keyboard and
terminal. The BIOS type and settings vary depending on the MCP-ATS model.
The procedure for viewing and setting the BIOS for each MCP-ATS type is displayed
below.
To move among the Main menu screen options, follow the navigation keys on

the screen.
To move among the list of parameters, use the navigation arrow keys.

Verify that the values set for the parameters are correct.
Manufacturer Card Type
Tadiran
Tadiran Telecom
SBS SBS-CT7
SBS-CT9
Motorola CPV5350-500
CPV5370
* BIOS (Basic Input Output System) program which is permanently located in a computer's mem-
ory and is activated at startup
If the BIOS Setup Configuration procedure for your card type is not described
below, refer to the manufacturer's website as follows:
1. From your workstation, open the Web browser and access the manufacturer's web site
at http://www.tadirantele.com.
2. Go to Partners login, type your username and password.
3. Click Enter. The Main Partners page is displayed.
4. Go to Support.
5. Refer to the list of card models supplied for the MCP-ATS and execute its
corresponding BIOS Setup procedure.
BIOS * Settings Procedure
BIOS Settings for the P-ATS Tadiran Telecom, page 8-40
BIOS Settings for the SBS-CT7, page 8-41
•
and
BIOS Settings for the SBS-CT7
•
P70500470CW24 V4.D, page 8-47
BIOS Settings for the SBS-CT9, page 8-48
BIOS Settings for the Motorola CPV5350 Models, page 8-50
BIOS Settings for Motorola CPV5370, page 8-60
Common Control Cards
8-39
