Figure 8-36 PBD-ATS

Card Layout

8-110
Common Control Cards
6. Grasp the replacement PBD-ATS by the handle and place the card so that it
connects with the shows on the backplane. The levers should stand parallel to
the backplane.
7. Refasten the screws.
8. Reconnect the cables.
9. Return power to the Coral System.
P2
P3
Front View
For upgrading older low density peripheral shelves with the PBD-ATS, see
the instructions provided in the upgrade kit.
P1
J11
J12
1
P6
4
1
P7
4
Coral FlexiCom 6000 Installation Manual
J21
J22
Back View
