Figure 8-5 Inserting the
Control Card
Coral FlexiCom 6000 Installation Manual
Ejector
Latch
1
Press latches.
Push ejectors
2
in direction
of arrows.
3
Insert card.
At end of slot,
push ejectors in
4
direction of
arrows.
Common Control Cards
8-11
