6-24
Cabinet Descriptions
*
Set Peripheral
Shelf Unit Shelf #
18 Unit 4 8 and 9
19 Unit 4 8 and 9
20 Unit 4 8 and 9
21 Unit 5 10 and 11
22 Unit 5 10 and 11
23 Unit 5 10 and 11
24 Unit 5 10 and 11
25 Unit 6 12 and 13
26 Unit 6 12 and 13
27 Unit 6 12 and 13
28 Unit 6 12 and 13
29 Unit 7 14 and 15
30 Unit 7 14 and 15
31 Unit 7 14 and 15
32 Unit 7 14 and 15
* The odd numbered shelf may not exist in some Peripheral Shelf Units.
† Slots 1 and 2 of the even shelf contain PB-ATS cards and do not use the Time Slots.
For a completely non-blocking system, the technician should avoid installing
the following cards in slots 1-8 of peripheral shelves 6 and 7:
30T/x, T1, PRI24, PRI 30, IPG, PUGW, UGW-E and UGW.
Tip:
If a number of heavy consumer cards are to be installed in Peripheral Shelf
Units, determine which slot sets are least blocking by referring to
Insert the first heavy consumer card in one of the slot sets, the next card in
the next least blocking slot set, etc.
When possible, avoid installing more than one heavy consumer card in a
single slot set.
Peripheral Card
Slots
5-8
9-12
13-18
1 - 4
5-8
9-12
13-18
1 - 4
5-8
9-12
13-18
1 - 4
5-8
9-12
13 -18
# of Number of Time
Peripheral Slots
Card Slots
8 slots 128
8 slots 128
12 slots 128
†
6 slots 128
8 slots 128
8 slots 128
12 slots 128
†
6 slots 128
8 slots 128
8 slots 128
12 slots 128
6 slots † 128
8 slots 128
8 slots 128
12 slots 128
Coral FlexiCom 6000 Installation Manual
Table 6-4.
