Table 6-2 Card Slot to
I/O Pair Relationship
Table 6-3 Card Slot to
I/O Champ Connector
Relationships
Coral FlexiCom 6000 Installation Manual
Cable Pairs Card Slots
1-8 upper
1-8 lower 3,5,7,9,11,13,15,17
9-16 upper
9-16 lower
17-24 upper 4,6,8,10,12,14,16,18
17-24 lower
25 Not Used
Associated
Card Slots Connector
3, 4
5, 6
7, 8
9, 10
11, 12
13, 14
15, 16
17, 18
Slot
Odd
Even
Even
Odd
—
Upper Lower
Connector
J37 J38
J39 J40
J41 J42
J43 J44
J45 J46
J47 J48
J49 J50
J51 J52
