Coral
FlexiCom 6000
Installation Procedure
and Hardware Reference
Manual
(Edition 6. )
Creating a new world of IPportunities

Advertisement

Table of Contents

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the Coral FlexiCom 6000 and is the answer not in the manual?

Questions and answers

Related Manuals for Tadiran Telecom Coral FlexiCom 6000

Summary of Contents for Tadiran Telecom Coral FlexiCom 6000

  • Page 1 Coral FlexiCom 6000 Installation Procedure and Hardware Reference Manual (Edition 6. ) Creating a new world of IPportunities...
  • Page 3 The information contained in this document is proprietary and is subject to all relevant copyright, patent and other laws protecting intellectual property, as well as any specific agreement protecting TADIRAN TELECOM LTD.'s (herein referred to as the "Manufacturer") rights in the aforesaid information. Neither this document nor the information contained herein may be published, reproduced or disclosed to third parties, in whole or in part, without the express, prior, written permission of the Manufacturer.
  • Page 5 Federal Communications Commission Rules Part 68 Compliance Statement This equipment complies with Part 68 of the FCC rules. On this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment.
  • Page 6 CE Compliance Statement (R & TTE) Equipment certified according to CE has been tested and complies with the following: EN 60950-1 EN 55022 CISPR 22 EN 55024 CISPR 24 Australia and New Zealand Compliance Statement Equipment certified for Australia and New Zealand has been tested and complies with the following: AS/NZS 4117 AS/NZS 60950.1 ACA TS001 TS002 TS003 TS004...
  • Page 7 Federal Communications Commission Part 15 The FCC Wants you to Know This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 8: Waste Of Electrical And Electronic Equipment

    For the purpose of this paragraph, the term “Distributor” shall mean the person and/or entity engaged in the importation, distribution, sales, support or any other activity carried out in the applicable jurisdiction in connection with products supplied by Tadiran Telecom Ltd.

  • Page 9: Table Of Contents

    Table of Contents 1 Introduction Document Description ..........................1-1 Document Contents ............................1-1 Related Documentation ..........................1-3 System Description .............................1-5 System Overview..............................1-5 Hardware Design ..............................1-8 Updating from the Coral FlexiCom 5000....................1-8 Special Symbols ............................1-9 Recommended Tools ..........................1-11 2 Hardware Installation Procedure Site Inspection ...............................2-1 Space Requirements ............................2-1 Installation Environment ..........................2-3...
  • Page 10 External Connections ..........................5-1 External Connections ............................5-1 6 Cabinet Descriptions Cabinet Descriptions ..........................6-1 Cabinet Structure ..............................6-1 Card Slot Assignments ...........................6-5 Input/Output Champ Connections......................6-15 Input/Output RJ-45 Connections .......................6-19 Peripheral Highway Cabling........................6-21 Tips for Peripheral Card Distribution ......................6-23 TOC-2 Coral FlexiCom 6000 Installation Manual...
  • Page 11 Control Card Assignments ..........................8-6 Card Handling Procedures ..........................8-7 Inserting and Removing a Control Card ....................8-9 Lithium Backup Batteries..........................8-14 Fan Tray................................8-15 MCP-ATS ................................8-17 General Description ............................8-17 MCP-ATS Card Types ...........................8-18 Coral Versions Compatibility with MCP-ATS Card Type ..............8-18 TOC-3 Coral FlexiCom 6000 Installation Manual...
  • Page 12 General Description ............................8-99 Circuit Description ............................8-103 Front Panel Indicators ..........................8-105 PBD-ATS ..............................8-107 General Description .............................8-107 Card Description ............................8-109 Replacing a PBD-ATS Card ........................8-109 PBD24S ................................. 8-111 General Description ............................. 8-111 Card Description ............................8-112 TOC-4 Coral FlexiCom 6000 Installation Manual...
  • Page 13 List of Figures Figure 2-1: Coral MDF Space Requirements ......................2-2 Figure 2-2: Coral FlexiCom 6000with an External Power Supply................2-13 Figure 2-3: Two Coral Cabinets with Battery Chargers Layout ................2-14 Figure 2-4: FlexiCom 6000 DC Power Cable Routes (side and rear views)............2-15 Figure 2-5: Coral DC Power Input Terminals......................
  • Page 14 Figure 6-14: Connector Pair Allocation........................6-18 Figure 6-15: Connection Layout for 66 Type Punch Blocks ..................6-18 Figure 6-16: Coral FlexiCom 6000 RJ-45 I/O Connections from Front Panel to Rear Panel ........6-19 Figure 6-17: H624 Crossover Cable ........................6-20 Figure 6-18: PCM Highway Distribution........................
  • Page 15 Figure 8-7: Control Shelf Fan Tray .......................... 8-16 Figure 8-8: MCP-ATS (Tadiran Telecom) Layout ....................8-21 Figure 8-9: MCP-ATS (Tadiran Telecom) Layout with an Hard Disk ............... 8-22 Figure 8-10: MCP-ATS (SBS-CT7) Layout......................8-23 Figure 8-11: MCP-ATS (SBS-CT9) Layout......................8-24 Figure 8-12: MCP-ATS (Motorola CPV 5350) Layout....................
  • Page 16 Figure 8-15: MCP-ATS (SBS-CT7) Front Panel Upright Position................8-35 Figure 8-16: MCP-ATS (SBS-CT9) Front Panel Upright Position................8-36 Figure 8-17: MCP-ATS (Motorola CPV 5350) Front Panel Upright Position ............8-37 Figure 8-18: MCP-ATS (Motorola CPV 5370) Front Panel Upright Position ............8-38 Figure 8-19: ...
  • Page 17 Chapter Introduction 1.1 Document Description ............1-1 1.2 System Description...............1-5 1.3 Special Symbols ..............1-9 1.4 Recommended Tools ............1-11 Coral FlexiCom 6000 Installation Manual...

  • Page 19: Introduction

    All of the components and issues relevant to the installation of the Coral FlexiCom 6000 system design are detailed in this document. The Coral FlexiCom 6000 system design incorporates a fully redundant backup System Description on page 1-5 system. See for a basic description of the Coral FlexiCom 6000 system.
  • Page 20 Hardware Reference The Hardware Reference Manual consists of Chapters 6 through 8. These chapters, as listed below, offer detailed technical information about Coral FlexiCom 6000 system hardware, including cabinet specifications, internal power supplies, and control card circuitry:. Chapter...

  • Page 21: Related Documentation

    Descriptions and Coral FlexAIR (Wireless (Wireless) Installation Systems) Installation Manual Procedure IP device (VoIP) Installation Coral VoIP Installation Manual Peripheral cards Descriptions and Coral Service and Peripheral Installation Cards Installation Manual Procedure Shared Service cards Coral FlexiCom 6000 Installation Manual Introduction...
  • Page 22 121S, 280, 280D, 280D-Z, 280S, 281S, APDL, PEX, APA and CPA) Digital Station Terminal Equipment Installation Manual DKT, DST, and VDM Digital Station Terminal Equipment Installation Manual FlexIP SoftPhone User Guide SeaBeam Installation and Administration Manual Introduction Coral FlexiCom 6000 Installation Manual...

  • Page 23: System Description

    Coral FlexiCom 6000 Redundancy The Coral FlexiCom 6000 system is a non-stop, non-blocking operation. The system’s Hot Standby dual control option includes two complete sets of control hardware, each able to fully and independently control the operations of the entire system. The two...
  • Page 24 The Coral FlexiCom 6000 /R (Redundant) Hot Standby dual control system provides complete battery protected backup coverage. The Coral FlexiCom 6000 system may also be used in a single control set configuration without using the redundancy option. Details about the system configurations can be found in Table 1-1 below.
  • Page 25 Table 1-1 Coral Specifications FlexiCom FlexiCom FlexiCom 6000 System 6000 6000/R Configurations Quantity Of Common Control Sets Group Controller Type 32GC 32GC Max. Number of Peripheral Sets Max. Number of Peripheral Shelves per System Max. Combined Trunk and Station 6,000 6,000 Ports per System Max.

  • Page 26: Hardware Design

    Hardware Design ....................The Coral FlexiCom 6000 system is built on a free standing, floor mount Main cabinet, serving as the system’s foundation. Each system includes one main cabinet, which contains the Control Shelf with either one control card or two control cards, depending on whether it is a single or dual control system.

  • Page 27: Special Symbols

    A page that is intentionally left blank, and may be used for reader information. This manual includes information for the Coral configurations in all geographic market areas. Much of the information is relevant for all hardware configurations and all market areas. Coral FlexiCom 6000 Installation Manual Introduction...
  • Page 28 NOTES: 1-10 Introduction Coral FlexiCom 6000 Installation Manual...

  • Page 29: Recommended Tools

    Telephone Line Test set capable of pulse and DTMF dialing  Portable (laptop) personal computer capable of emulating an asynchronous  ASCII data terminal and approved by the manufacturer to run the Binary 1-11 Coral FlexiCom 6000 Installation Manual Introduction...
  • Page 30  ” and ” Cable Staple Gun    Analog Line Transmission Analyzer  Portable DS1/E1 Analyzer, Bit Error Rate Tester, and channel demultiplexer  Related Documentation: Related Documentation, page 1-3  1-12 Introduction Coral FlexiCom 6000 Installation Manual...

  • Page 31: Hardware Installation Procedure

    Chapter Hardware Installation Procedure 2.1 Site Inspection ..............2-1 2.2 Equipment Installation ............2-7 2.3 Program Interface Device Connection........2-49 Coral FlexiCom 6000 Installation Manual...

  • Page 33: Site Inspection

    The MDF should be located immediately adjacent to the Coral cabinet. The bottom of the MDF should be no lower than 2 feet (61cm) and the top should be no higher than 6 feet (1.9 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...

  • Page 34: Figure 2-1 Coral Mdf Space Requirements

    5. Verify that there is sufficient space for Power Backup equipment, if it is provided as part of the installation. No specific requirements can be detailed in this procedure, because of the great variety of Power Backup Equipment that is available. Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 35: Installation Environment

    If batteries are installed as part of the system, ensure that adequate precautions are taken (such as special ventilation) to prevent corrosive emissions from the batteries. Check local building codes for additional requirements. Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 36 Main with 2 Peripheral Shelves 2,048 3,755 Main with 3 Peripheral Shelves 3,072 5,461 Expansion: 2 Peripheral Shelves 1,878 3,413 Expansion: 3 Peripheral Shelves 2,817 5,120 Expansion: 4 Peripheral Shelves 3,756 6,826 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 37: Electrical Requirements

    4. CAUTION! This equipment is designed to permit connection between the earthed conductor of the DC supply circuit and the earthing conductor at the equipment. See installation instructions below. 5. The equipment shall be connected to a properly earthed supply system. Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 38 Main with 3 Peripheral Shelves 2 Shelf Expansion Add 10A Add 5A Add 12A 3 Shelf Expansion Add 15A Add 10A Add 18A 4 Shelf Expansion Add 20A Add 10A Add 24A Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 39: Equipment Installation

    8. Remove the plastic bag containing extra cabinet hardware and cabinet placement instructions, and place it aside. 9. Lift and remove the wrap-around side panel of the shipping carton and set aside. Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 40 Then spin the leveling foot anti-clockwise to retract it away from the floor. Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 41: Cabinet Mounting And Placement

    (RFI). The plastic bag containing extra cabinet hardware and cabinet placement instruction includes 15 flat washers which may be placed over the hinge pin at Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 42 7. Reassemble the shipping carton components and set the shipping carton aside. Once the system is completely installed and operating, it is no longer necessary to keep the shipping carton. 2-10 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 43: Ground And Power Wiring

    2. Release the two locking screws from the power input cavity and remove the cover and retain it. Also remove the cable clamps and retain them, see Figure 2-5. 2-11 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 44 One is located on the cabinet front-left bottom and the other on the cabinet top, behind the cable clamps. Forcibly push up the covers, releasing them from their spring fixings and discard. 2-12 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 45: Figure 2-2 Coral Flexicom 6000With An External Power Supply

    Breaker Panel To AC Power Ground Cable Entry Clamp Power Cable Entry Clamp FUSE 30A / 60V SPARE FUSE Power Input Card -48V SGND Building Entrance Ground Coral FlexiCom 6000 Cabinet 2-13 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...

  • Page 46: Figure 2-3 Two Coral Cabinets With Battery Chargers Layout

    30A / 60V 30A / 60V Panel SPARE FUSE SPARE FUSE -48V -48V Power Input Power Input Card Card SGND SGND To AC Power Coral FlexiCom 6000 Cabinets Building Entrance Ground 2-14 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 47: Figure 2-4 Flexicom 6000 Dc Power Cable Routes (Side And Rear Views)

    Loops Over Here Power Input Cavity Route Power Cable from Bottom Hole Upward Along the Left Side Rear View Side View Hole for Cable Entry Power Cable Enters from Bottom Bottom View 2-15 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 48 10. Use cable ties to secure each of the conductors to the Cable Tie-Off Bracket on the top of the cabinet, leaving sufficient slack in each conductor to prevent strain. 11. Replace the Power Input Cavity Cover and screw into place. 2-16 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 49 12. Install the front and rear cabinet nameplates at the top of the cabinet front and rear, respectively. Input/Output (I/O) Cables beginning on page 2-20. 13. Continue with 2-17 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...

  • Page 50: Figure 2-5: Coral Dc Power Input Terminals

    Power Input Terminals Ground Cable Power Cable Entry Clamp Entry Clamp FUSE 30A / 60V SPARE FUSE (Power Input Card) -48V SGND Power Input Cover 6000 Decorative Panel Pull to Remove 2-18 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 51 NOTES: 2-19 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...

  • Page 52: Input/Output (I/O) Cables

    I/O cables are in place. If the I/O cables enter the cabinet from the bottom, route the first cable to the lower right connector (J38) on the lower peripheral shelf. Insert the cable 2-20 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 53 17, 18 Never route RJ-45 cables through the bottom, as this may cause RFI RJ-45 I/O Cable disturbances within the system. For further information, see Connections (LDF and UDF), page 2-25. 2-21 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...

  • Page 54: Figure 2-6 Coral I/O Champ Cable Routes From Bottom Of Cabinet (Rear View)

    Champ Cable Routes from Bottom of Cabinet (rear view) Route I/O Cables Through Guide Rings Along Right Side of Backplane I/O Cables from Bottom Enter Here Knockout Panel for I/O Cables Entry 2-22 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 55: Figure 2-7 Coral I/O Champ Cable Routes From Top Of Cabinet (Rear View)

    Top of Cabinet RJ-45 I/O Cables (rear view) Enter Here Cover Screw I/O Cables from Top Enter Here Route I/O Cables through Guide Rings along Right Side of Backplane Rear View 2-23 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...

  • Page 56: Figure 2-8 Coral Card Slot Position To I/O Cable Pair Relationship

    Coral FlexiCom 5000, 6000 Ensure that each I/O cable is secured with its own hook-and-loop fastener strap on the Coral cabinet rear, so that the cables do not accidentally pop out of place. 2-24 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 57 2-9) on either the LDF panel or UDF panel, as follows: LDF for CLA, PUGW, UGW, UGW-E or IPG peripheral cards  UDF for PRI-23, PRI-30, T1, 30T, or 30TM peripheral cards (layout UDT  or 2DT). 2-25 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 58 Install an additional LDF (Catalog Number 7244-9043100) or UDF (Catalog Number 7244-9044100) panel as required. 10. Install the rear cabinet nameplates at the top rear section of the cabinet. See Figure 2-11. 2-26 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 59: Figure 2-9: Coral Cabinet I/O Rj-45 Crossover Cable Routing

    LDF for MAP, CLA, PUGW, UGW-E, UGW, IPG Cabinet I/O RJ-45 UDF for PRI/T1/30T/30TM (layout UDT/2DT) Crossover Cable Routing (Optional) PUGW T1/PRI/30T/30TM RJ-45 Crossover Cables (layout UDT/2DT) H624 (Cat. No. 7244-8000624) to Front Panels of Peripheral Cards 2-27 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...

  • Page 60: Figure 2-10: Coral I/O Rj-45 Cables Routing

    RJ-45 Cables from PSTN or LAN / WAN Enter Here RJ-45 Cables PSTN or LAN / WAN RJ-45 Crossover Cables H624 (Cat. No. 7244-8000624) to Front Panels of Peripheral Cards Rear View 2-28 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 61: Figure 2-11: Coral Ldf/Udf Rj-45 Connectors

    Figure 2-11 Coral LDF/UDF RJ-45 Connectors 6000 Pull to Remove Decorative Panel 2-29 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...

  • Page 62: Power Supplies

    (slot PS3). This slot is for future Coral Configurations. Install the PPS and RPS units in their slots on the peripheral shelves, if not installed already. 2-30 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 63 3-1), these units should be administered partially extracted from their slots so that they protrude by approximately 1 inch (2.5cm). Only after verifying the external power should they be reinserted properly and fastened. 2-31 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...

  • Page 64: Circuit Card Installation

    Verify that the card is oriented correctly. Align the edges 2-32 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 65 It has rounded corners similar to the control cards of other Coral systems. The PB-ATS card slides into matching groves in slots 1 and 2. 2-33 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 66 4 of two even numbered peripheral shelves in the Main cabinet. The cards inserted in these slots are used to synchronize the Coral system clock with a network clock signal via a Digital Trunk Circuit, as they 2-34 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 67 For a completely non-blocking system, the technician should avoid installing the following cards in slots 1-8 of peripheral shelves 6 and 7: 30T/x, T1, PRI24, PRI 30, IPG, UGW, UGW-E and PUGW. 2-35 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 68 8/16SKK VoIP Interface PUGW , UGW, UGW-E, IPG, FlexiGate-BRI, FlexiGate-E&M Peripheral Auxiliary Interface 8DRCM , 8DRCF , RMI These cards require changes to option straps which affect interface characteristics or operation. 2-36 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 69: Figure 2-12 Even Numbered Shelf - Peripheral Card Placement

    ....PB-ATS PB-ATS Card Type: ....2-37 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...

  • Page 70: Figure 2-13 Odd Numbered Shelf - Peripheral Card Placement

    ........2-38 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 71 Common Control Card Installation The Coral FlexiCom 6000 includes a single set of common control cards, always located on the right side of the shelf, while the FlexiCom 6000/R includes two redundant sets of control cards. The FlexiCom 6000/R includes two sets of control cards that stand side by side on the same shelf.

  • Page 72: Figure 2-14 Control Card Slots For A Redundant System

    CLA-ATS is shipped separately and must be installed separately, see CLA-ATS Card on page 8-88 for the installation procedure for the CLA-ATS card. All the control shelf cards must be partially extracted from the Control Cage before system initialization. 2-40 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 73: Cabling Between The Control And Peripheral Shelves

    Cabling between the Control and Peripheral Shelves ....................The 32GC is the heart of the Coral FlexiCom 6000 system. A physical connection must be constructed between the single 32GC or both 32GC cards and each peripheral shelf, odd or even. The even peripheral shelves must have a hard-wire connection between the PB-ATS cards and each 32GC card.

  • Page 74: Figure 2-15 Backplane Wiring Schematic For Peripheral Shelves To Control Shelf

    Wiring Schematic for Peripheral Shelves to PBD24S Control Shelf Odd Shelf FC16 Cable Backplane PBD-ATS PB-ATS PB-ATS FC19 Cable FC19 Cable MPG-ATS Right Left 32GC 32GC Even Shelf H-41 Cable Backplane 2-42 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 75 4. Connect the other side of the first FC19 cable to the next available PBD-ATS P3 connector until locked into place. For Redundant systems, connect the other side of the second FC19 cable to the same PBD-ATSs P2 connector. 2-43 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 76 3. Connect the other side of the FC16 cable to P1 on the even shelf above or below this shelf, see Figure 2-16. 4. Repeat this procedure for each “unconnected” odd shelf. 2-44 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 77: Figure 2-16 Pbd24S To Pbd-Ats Cabling

    Figure 2-16 PBD24S to PBD-ATS Cabling PBD24S FC16 flat cable Odd shelf PBD-ATS Even shelf 2-45 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...

  • Page 78: Figure 2-17 Mpg-Ats With Ground Connections

    FC-19 cable P1 1 PBD-ATS P2 GND 5 GND 12 GND 4 GND 13 GND 3 GND 14 GND 2 GND 15 FC-19 cable PBD-ATS P3 MPG-ATS GND 16 GND 1 2-46 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 79: Figure 2-18 Pbd-Ats Ground Connections

    Figure 2-18 PBD-ATS PBD-ATS Ground Connections FC-19 cable MPG-ATS P9 GND2 Ground cables GND3 FC-19 cable MPG-ATS P1 2-47 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 80 NOTES: 2-48 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 81: Program Interface Device Connection

    The PI device must use the ASCII character set. The earth ground connection to the PI device must be the same earth ground connection supplied to the Coral system. 2-49 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 82 Leave approximately 24 inches (60cm) of cable on the front side of the cabinet to reach the front panel of the MCP-ATS card installed on the Common Control shelf without interfering with the insertion or removal of any circuit cards or power supplies. 2-50 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 83: Figure 2-19: Pi Db9 Terminal To Kb0 Connection

    RECEIVE DATA - 3 2 - RECEIVE DATA TRANSMIT DATA - 2 PC Async. Serial Port PROGRAMMING PORT or Async.Data Terminal (USE FEMALE CABLE 9 PIN CONNECTOR) (USE FEMALE CABLE CONNECTOR) 2-51 Coral FlexiCom 6000 Installation Manual Hardware Installation Procedure...
  • Page 84 2-52 Hardware Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 85: Initial Power-Up Tests

    Chapter Initial Power-Up Tests 3.1 Power Supply Test ..............3-1 3.2 Common Control Test ............3-9 3.3 Shared Service & Peripheral Interface Card Test ....3-19 Coral FlexiCom 6000 Installation Manual...

  • Page 87: Power Supply Test

    1 inch (2.5cm) from the front of the card cage. Also, turn off ALL peripheral power supplies: PPS and RPS units. These are to be switched on only after at least one Control Shelf PS-ATS is powered. Coral FlexiCom 6000 Installation Manual Initial Power-Up Tests...

  • Page 88: Power Input

    4. Insert the two screws into the power input cover and tighten them. 5. Push the front and rear decorative panels into place. 6. Repeat the above steps for each Coral cabinet in the system. Initial Power-Up Tests Coral FlexiCom 6000 Installation Manual...

  • Page 89: Figure 3-1 Power Input Terminals

    Figure 3-1 Power Input Terminals Ground Cable Power Cable Entry Clamp Entry Clamp FUSE 30A / 60V SPARE FUSE (Power Input Card) -48V SGND Power Input Cover 6000 Decorative Panel Pull to Remove Coral FlexiCom 6000 Installation Manual Initial Power-Up Tests...

  • Page 90: Common Control Power Supply Test

    Control Shelf. 3. Fasten the four captive screws on each corner of each PS-ATS to secure it into place. Figure 3-2 PS-ATS Front Panel: Upright Position PS-ATS POWER FAIL Initial Power-Up Tests Coral FlexiCom 6000 Installation Manual...

  • Page 91: Peripheral Shelves Test

    PPS. Insert the negative lead of the meter into the –48 (–) test point. Verify that there is approximately +48 volts between the two test points. 9. Turn OFF the power switch on the front panel of the PPS. Coral FlexiCom 6000 Installation Manual Initial Power-Up Tests...

  • Page 92: Figure 3-3 Pps - Peripheral Power Supply Test Points

    POWER SUPPLY INPUT Input fuse -48V PPS DC-DC converters INPUT Input fuse -48V PPS control & peripheral cards Power on green indicator Power switch Output voltage adjust Output test points +12V -12V -48V Initial Power-Up Tests Coral FlexiCom 6000 Installation Manual...
  • Page 93 4. Measure the AC voltage between the TP1 and TP2 test points. Verify that the DMM shows a voltage of approximately 75-105 volts AC. 5. Turn OFF the power switch on the front panel of the RPS. Coral FlexiCom 6000 Installation Manual Initial Power-Up Tests...

  • Page 94: Figure 3-4 Rps - Ring Generator Power Supply Test Points

    POWER SUPPLY INPUT INPUT BRV output -48VDC input fuse fuse Power Switch Power On Output indicator voltage adjust VOLTAGE ADJUST Test points OUTPUT 25 Hz 20 Hz Output 16 Hz frequency selector Initial Power-Up Tests Coral FlexiCom 6000 Installation Manual...

  • Page 95: Common Control Test

    4. Place the 32GC card on the anti-static sheet. 5. Carefully remove the plastic insulation from under the bottom of the lithium battery on the 32GC card. Coral FlexiCom 6000 Installation Manual Initial Power-Up Tests...
  • Page 96 Attach SAU own Coral Software box. Two separate Coral Software boxes are provided for HSB systems, one for the right side of the Control Shelf, and one for the left side. 3-10 Initial Power-Up Tests Coral FlexiCom 6000 Installation Manual...
  • Page 97 25. If not already installed, insert the appropriate compact flash memory (CFD) Installing a CFD in the Teknor disk into the drive on the CLA-ATS card side (see cPCI-MXP CLA-ATS Card, page 8-89). 3-11 Coral FlexiCom 6000 Installation Manual Initial Power-Up Tests...
  • Page 98 Messages for a Properly Loading Active Side Loading ... OMF 80286/80386 LOADER V2.01 Copyright 1992, Tadiran Corporation Loading /work/k.om8 Loading /work/d.om8 Loading /work/au.om8 Loading /work/p.om8 End Loading File...! Start Build Checksum End Build Checksum 3-12 Initial Power-Up Tests Coral FlexiCom 6000 Installation Manual...
  • Page 99 Initializing CLA card ..CCS is on the air ..(ROOT) CCS xx.xx.xx (ACTIVE) Copyright (c) 2001-yyyy ....NAME - (site name) SAU # - (date and time) Join process began Join process succeeded 3-13 Coral FlexiCom 6000 Installation Manual Initial Power-Up Tests...
  • Page 100 CHECK CHECKSUM... END CHECK CHECKSUM Attaching Device....Attaching Files....This is a HOT STAND BY SYSTEM Initializing CCS ... First Initialization starting .... First Configuration phase completed ..Partial initialization phase starting 3-14 Initial Power-Up Tests Coral FlexiCom 6000 Installation Manual...
  • Page 101 NAME - (site name) SAU # - Join process began (date and time) Changing configuration to STANDBY (ROOT) xx.xx.xx (STANDBY) Copyright (c) 2001-yyyy ....NAME - (site name) SAU # - Join process succeeded 3-15 Coral FlexiCom 6000 Installation Manual Initial Power-Up Tests...

  • Page 102: 32Gc Card Lithium Battery Test

    At that time the card battery (or batteries) may be replaced, and the system restarted. Verify that the CFD is installed in the MCP-ATS as the system starts, so that the system can read the database from the diskette back into database memory. 3-16 Initial Power-Up Tests Coral FlexiCom 6000 Installation Manual...
  • Page 103 There is a danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to requirements specified by the battery manufacturer and/or local regulatory agencies. 3-17 Coral FlexiCom 6000 Installation Manual Initial Power-Up Tests...
  • Page 104 NOTES 3-18 Initial Power-Up Tests Coral FlexiCom 6000 Installation Manual...

  • Page 105: Shared Service

    Turn on the PPS and RPS units only after powering the Control Shelf and verifying that the Control Shelf has initialized properly, otherwise the cards in the peripheral shelves may not initialize. 3-19 Coral FlexiCom 6000 Installation Manual Initial Power-Up Tests...
  • Page 106 A status field display of NO_RESOURCES indicates that the system Sizes are insufficient to support the card. 3-20 Initial Power-Up Tests Coral FlexiCom 6000 Installation Manual...
  • Page 107 The different card slot messages are described below in Table 3-1. For a complete list of card slot status messages, see Chapter 6 in the Program Interface & Database Reference Manual. 3-21 Coral FlexiCom 6000 Installation Manual Initial Power-Up Tests...
  • Page 108 Install an updated UNAUTHORIZED therefore the card is not authorized for version of the SAU use in this system. with the appropriate amount of ports added. Ask your dealer for an authorized upgrade. 3-22 Initial Power-Up Tests Coral FlexiCom 6000 Installation Manual...
  • Page 109 Chapter Software Installation Procedure 4.1 Generic Feature Software.............4-1 4.2 System Database Control.............4-3 4.3 Hot Standby Configuration Modes........4-13 4.4 Upgrading the Coral Version..........4-21 4.5 System Diagnostics ............4-25 Coral FlexiCom 6000 Installation Manual...

  • Page 111: Software Installation Procedure

    The Coral system is delivered to the site with factory-loaded software on the Compact Flash Disk(s) located on the MCP-ATS card(s). The generic software database for the Coral FlexiCom 6000 is saved on a battery backed up RAM located on the 32GC card. The Compact Flash Disk (CFD) installed in the MCP-ATS (two identical CFDs are stored in both MCP-ATSs for the Hot Standby system) holds the non-volatile copy of the database.
  • Page 112 PC using the Binary Backup PC-Utility. The Binary Backup is a tool for Coral technicians who install, upgrade and maintain Coral systems. See the Database Binary Backup PC Utility Reference Manual for further details. Software Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 113: System Database Control

    System Database Control The generic software database for the Coral FlexiCom 6000 is saved on a battery backed up RAM located on the 32GC card. The Compact Flash Disk (CFD) installed in the MCP-ATS (two identical CFDs are stored in both MCP-ATSs for the Hot Standby system) holds the non-volatile copy of the system database, the generic software and feature authorization.

  • Page 114: Saving The System Database

    Database File File Description Descriptions Name Entry DB0.DEF Daily back-up automatically at a preset time. DB1.DEF Technician copy for manual back-up. At the system prompt the following parameter is displayed: EXECUTE (Y/N) - Software Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 115 Press N to cancel and return to the Database Disk menu. The PI command prompt immediately returns, however the system processes the command (*:) as a background (low priority) task. Coral FlexiCom 6000 Installation Manual Software Installation Procedure...

  • Page 116: Loading (Restoring) The Database From The Cfd

    Database Disk menu. Loading the database from the CFD file generally takes a few seconds to a few minutes depending on the system size. After the database is loaded, the system performs a Partial Initialization and begins processing calls. Software Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 117: Copying Files On The Cfd

    3. Enter 0 for the source file and 1 for the destination file to copy DB0.DEF to DB1.DEF; or 1 and 0 , respectively, to copy DB1.DEF to DB0.DEF. At the system prompt: EXECUTE (Y/N) - Coral FlexiCom 6000 Installation Manual Software Installation Procedure...
  • Page 118 Main Processor. When the copy process is completed, the system reports: DB0.DEF COPIED TO DB1.DEF (or vice versa) Software Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 119: Viewing Cfd Directory Details

    (in MM/DD/YY format) and time (in HH:MM:SS format) that the file was written on the CFD. The FILE_STATUS field is valid only for database files, and indicates whether or not the file was written successfully. Coral FlexiCom 6000 Installation Manual Software Installation Procedure...

  • Page 120: Automatic Daily Database Back-Up

    1:30 a.m. The technician should choose a time when call traffic is lowest. 4. The system returns to the Database Backup menu. Press 0 to return to the Database Disk menu. 4-10 Software Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 121: Error Messages

    Copy Files — The Database CFD disk does not contain a valid source (may also specify DB1.DEF) database file. It is likely that the disk has never had a database saved to the source file. 4-11 Coral FlexiCom 6000 Installation Manual Software Installation Procedure...
  • Page 122 NOTES: 4-12 Software Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 123: Hot Standby Configuration Modes

    Hot Standby System Side Definitions ....................The Hot Standby (HSB) Coral FlexiCom 6000/R system is a redundant dual control system. One control is Active while the second remains in Standby mode. If the first system fails for any reason, the second, Standby system, automatically becomes Active so that there is no interruption of calls with this redundant system.
  • Page 124 Single Control systems Single Control system is on are not permissible Control the right side of the from the left side. control shelf. No Redundancy system is installed on the left side. 4-14 Software Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 125: Switching Between System Sides

    (Yes) or single control system (No). If this displays No, then the following parameters are not displayed. OTHER MCP Yes/No Displays whether the MCP-ATS is installed on the Read-Only other system side. EXISTS 4-15 Coral FlexiCom 6000 Installation Manual Software Installation Procedure...
  • Page 126 No_Comm NO_COMM indicates that this is currently not a redundant system. Update Status Yes/No Choose Yes to change the system status as chosen in the previous parameters. Choose No to retract. 4-16 Software Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 127 Press 0 to transfer this system side to Active mode. If NO_COMM is displayed, then this is currently not a redundant system. 6. The PI prompts: UPDATE STATUS (Y/N): Enter Yes to update the change requests. Enter No to retract. 4-17 Coral FlexiCom 6000 Installation Manual Software Installation Procedure...
  • Page 128 6. The system is now in I or I’ mode, with a stand-alone Active side (no redundancy). 7. Continue pressing Enter without changing any of the other parameters until you reach the last parameter to update the changes: UPDATE STATUS (Y/N): 4-18 Software Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 129 If AUTO MAINTENANCE TERMINATION was set to No, the technician must remember to manually return the system to Standby, when appropriate. This is done from the PI terminal of the Active side. 4-19 Coral FlexiCom 6000 Installation Manual Software Installation Procedure...
  • Page 130 8. Continue pressing Enter without changing any of the other parameters until you reach the last parameter to update the changes: UPDATE STATUS (Y/N): 9. Enter Yes to update the change requests. Enter No to retract. 4-20 Software Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 131: Upgrading The Coral Version

    3. Turn off all the PPS and RPS units in each peripheral shelf. 4. For card skip to Step 5. Remove the MCP-ATS (for Coral FlexiCom 6000/R (HSB) systems, remove Removing a Control both MCP-ATSs) by unscrewing and pulling them out, see Card on page 8-12.
  • Page 132 System Database on page 4-4. 13. In order for the Coral FlexiCom 6000/R system to function as a Hot Standby system, both MCP-ATSs must have the same Coral generic version loaded on their CFD cards. Otherwise, the system is not in Hot Standby mode and automatically reverts to a single sided system, where one side is Active, while the other side is Faulty and does not operate.
  • Page 133 Hot Standby systems require the same Coral generic version loaded on both system sides. Otherwise, the system functions as a single sided system with no redundancy! 4-23 Coral FlexiCom 6000 Installation Manual Software Installation Procedure...
  • Page 134 NOTES: 4-24 Software Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 135: System Diagnostics

    Press Enter to enable the default, which displays all the related parameters and their values. Table 4-5 displays the UNITS parameters below with a brief description of each parameter. Field numbers are displayed in brackets. 4-25 Coral FlexiCom 6000 Installation Manual Software Installation Procedure...
  • Page 136 1-Remote Remote Coral FlexLITE unit. Send To 32GC Card? [11] Yes/No Loads the modified UNIT information. When No is entered, updates are ignored and the system remains at its pre-programmed definitions. 4-26 Software Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 137: Pb-Ats Fault Messages

    Shelf #0 to #15 indicates which Peripheral Shelf holds the faulty PB-ATS  The highway number in which unit the fault is occurring (as applicable)  The time slot number in which unit the fault is occurring (as applicable)  4-27 Coral FlexiCom 6000 Installation Manual Software Installation Procedure...
  • Page 138 The PI test options can be obtained from the Root, 1, 0 branch. See Chapter 22 of the relevant Program Interface and Data Reference Manual for further details. Selecting a test not relevant for the Coral FlexiCom 6000 systems, results in the following message:...
  • Page 139 ATS Disk Alarm CNTL Alarm Batteries Alarm These messages indicate a faulty item for the Standby system side of a Hot Standby system and is not relevant for single sided systems. 4-29 Coral FlexiCom 6000 Installation Manual Software Installation Procedure...
  • Page 140 Chapter 22 of the relevant Program Interface & Database Reference Manual for further details. If the system contains no alarms when the technician requested an alarm report, the message is displayed. No Active Alarms 4-30 Software Installation Procedure Coral FlexiCom 6000 Installation Manual...
  • Page 141 Operator’s Console Indicators The following malfunction indicators, specific to the Coral FlexiCom 6000, appear on the Central Switchboard of the Telephone Attendant. Activation of alarms are signaled by a flashing light on the operator’s console and the stated Attendant message.
  • Page 142 5. Press Enter. The PI prompts: SEND TO 32GC (Y/N) -N Enter Yes to send the updated information to the card and complete the requested changes. Enter No to retract. 4-32 Software Installation Procedure Coral FlexiCom 6000 Installation Manual...

  • Page 143: External Connections

    Chapter External Connections 5.1 External Connections............5-1 Coral FlexiCom 6000 Installation Manual...

  • Page 145: External Connections

    Coral FlexiCom 300, 400, 5000 Installation Procedure and Hardware Reference Manual. The pinout tables for MDF connections are described. The tables are used during the installation procedure performed in Chapter 2 of this manual. Coral FlexiCom 6000 Installation Manual External Connections...
  • Page 146 NOTES: External Connections Coral FlexiCom 6000 Installation Manual...

  • Page 147: Cabinet Descriptions

    Chapter Cabinet Descriptions 6.1 Cabinet Descriptions.............6-1 Coral FlexiCom 6000 Installation...

  • Page 149: Cabinet Structure

    Cabinet Structure ....................The Coral FlexiCom 6000 is housed in one or more free-standing, floor mounted main cabinet, serving as the system’s foundation. The system consists of one main cabinet, which houses the Coral FlexiCom 6000 Control Shelf and two or three Peripheral shelves.

  • Page 150: Figure 6-1: Coral Flexicom 6032Xx: Main Cabinet Structure And Card Slot Assignments For A 3-Shelf Cabinet

    FlexiCom 6048xx: Main Cabinet Structure and Card Slot Assignments for a 4-shelf cabinet Universal I/O slots Shared service or PB-ATS slots Peripheral & ringer power supplies Left common control Right common control tray Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...

  • Page 151: Figure 6-3 Coral Flexicom 6000 Cabinet Door Latch Operation Detail

    Cabinet Components Card Cages/Shelves The Coral FlexiCom 6000 slot cabinet contains three or four card cages can, also referred to as shelves. These cabinets are designed to provide a simple, reliable method for installing and removing the printed circuit cards and assemblies, which contain the active circuitry of the system.
  • Page 152 6-7. Peripheral Shelf UNIT Definition The Coral FlexiCom 6000 system may be composed of up to eight peripheral Shelf UNITs (with regard to system time slots). Each Unit is always includes an Even numbered shelf. It may also include one odd numbered, adjacent, shelf. The Even numbered shelves include at least one PB-ATS card which supplies 512 time slots to the UNIT (either one shelf or two shelves).

  • Page 153: Card Slot Assignments

    Control Shelf. The Fan tray and three fan fuses are located at the bottom of the Control Shelf. See Chapter for further details about the Power Supply Units. See Chapter for details about the Common Control Shelf cards. Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...

  • Page 154: Figure 6-4: Control Shelf With Coded "Keys" Placement

    Figure 6-4 Control Shelf with Coded “Keys” Placement Top row Bottom row of coded keys of coded keys 32 GC CLA-ATS (optional) MCP-ATS PS 1 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...

  • Page 155: Figure 6-5 Single Control Shelf - Front View

    Fuses 1 2 3 FAN-1 FAN-2 FAN-3 Fuse Fuse Fuse Figure 6-6 Redundant LEFT RIGHT (Dual) Control Shelf - control control Front View Fuses 1 2 3 FAN-1 FAN-2 FAN-3 Fuse Fuse Fuse Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...
  • Page 156 PBD-ATS, see 8-107. Cabinet Card Slot Assignment Illustrations Figures illustrate the Coral FlexiCom 6000 slot distribution for a main cabinet loaded with 3 peripheral shelves and a main cabinet loaded with 2 peripheral shelves. Figures 6-9, 6-10,...

  • Page 157: Figure 6-7: Main Cabinet With 3 Peripheral Shelves: Front - Card Slot Assignment Shelf

    Cabinet with 3 Peripheral Shelves: Front - Card Slot Assignment Shelf Main Cabinet- Shelf Main Cabinet- Third Shelf Main Cabinet- Second Shelf Fuses 1 2 3 Bottom Shelf Control Shelf FAN-1 FAN-2 FAN-3 Fuse Fuse Fuse Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...

  • Page 158: Figure 6-8 Main Cabinet With 2 Peripheral Shelves: Front - Card Slot Assignment

    Figure 6-8 Main Cabinet with 2 Peripheral Shelves: Front - Card Slot Assignment Fuses 1 2 3 FAN-1 FAN-2 FAN-3 Fuse Fuse Fuse 6-10 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...

  • Page 159: Peripheral Shelves Installed: Front Card Slot Assignment

    Figure 6-9 3 Shelf Expansion Cabinet with 3 Peripheral Shelves installed: Front - Card Slot Assignment 6-11 Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...

  • Page 160: Figure 6-10: 3 Shelf Expansion Cabinet With

    Figure 6-10 3 Shelf Expansion Cabinet with 2 Peripheral Shelves installed: Front - Card Slot Assignment 6-12 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...
  • Page 161 Figure 6-11 4 Shelf Expansion Cabinet with 3 Peripheral Shelves installed: Front - Card Slot Assignment 6-13 Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...
  • Page 162 Figure 6-12 4 Shelf Expansion Cabinet with 4 Peripheral Shelves installed: Front - Card Slot Assignment 6-14 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...

  • Page 163: Input/Output Champ Connections

    Refer to the specific card tables in Chapter 5-External Connections in the Coral FlexiCom 300, 400, 5000 Installation Manual for I/O connector pin assignments. There are no I/O connector pin assignments for the power supplies, Common Control cards or Shared Service cards. 6-15 Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...

  • Page 164: Figure 6-13 Coral

    Figure 6-13 Coral FlexiCom 6000- Backplane Slot Diagram - Rear View UNIVERSAL I/O SLOTS POWER SUPPLIES P7 P8 P1 1 MPG-ATS 6-16 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...
  • Page 165 Table 6-3 Card Slot to Associated Upper Lower I/O Champ Connector Card Slots Connector Connector Relationships 3, 4 5, 6 7, 8 9, 10 11, 12 13, 14 15, 16 17, 18 6-17 Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...

  • Page 166: Figure 6-14 Connector Pair Allocation

    EVEN SLOTS 20/45 Yellow/slate Ports 0-7 Ports 16-23 21/46 Violet/blue 22/47 Violet/orange 23/48 Violet/green 24/49 Violet/brown Vio/Brn Vio/Brn 25/50 Violet/slate Pair 25 Pair 25 Not used Not used Coral FlexiCom 5000, 6000 6-18 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...

  • Page 167: Input/Output Rj-45 Connections

    H624 crossover cable. The crossover cable ensures that the pinout order from the peripheral cards remain constant from the front panel to the LAN/WAN/PSTN/CSU/LTU connection, see Figure 6-17. 6-19 Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...

  • Page 168: Figure 6-17: H624 Crossover Cable

    (RFI) and meet or exceed all requirements and specifications of telecommunications and electrical safety authorities world-wide. The Coral FlexiCom 6000 cabinet is supplied with: 1 (one) LDF panel (four RJ-45 connectors for UGW, UGW-E, PUGW and  IPG cards) 4 (four) H624 crossover cables ...

  • Page 169: Peripheral Highway Cabling

    Peripheral Highway Cabling ....................The Peripheral Bus of the Coral FlexiCom 6000 system is extended from the MPG-ATS backplane card in back of the Common Control Shelf to the PBD-ATS card Odd or Even Shelves on on the backplane of the even numbered Peripheral Shelves (see page 6-26) via one or two redundant multi-conductor FC19 cables.
  • Page 170 PCM highway A3 supports cards 9 to 12 in both even and odd shelves. If only one shelf existed, the 512 time slots would be divided only among the even shelf thereby enhancing call traffic. 6-22 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...

  • Page 171: Tips For Peripheral Card Distribution

    Tips for Peripheral Card Distribution ....................When installing a new Coral FlexiCom 6000 system, it is recommended that the time slot (PCM highway) distribution among the peripheral shelf slots be taken into account when planning the peripheral interface cards location.
  • Page 172 Insert the first heavy consumer card in one of the slot sets, the next card in the next least blocking slot set, etc. When possible, avoid installing more than one heavy consumer card in a single slot set. 6-24 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...

  • Page 173: Figure 6-18 Pcm Highway Distribution

    SLOT 8 SLOT 9 SLOT 10 SLOT 11 SLOT 12 SLOT 13 SLOT 14 SLOT 15 Coral FlexiCom 6000 SLOT 16 512 time slots per Peripheral Shelf Unit SLOT 17 SLOT 18 6-25 Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...

  • Page 174: Peripheral Shelf Numbering

    Therefore, the shelf number must be determined. The peripheral shelves in the Coral FlexiCom 6000 are divided into Peripheral Shelf Units where each Unit consists of one or two peripheral shelves that share at least one PB-ATS card.

  • Page 175: Figure 6-20 Flexicom 6000 - With Shelf Id Jumper Locations And Strapping

    Odd Shelf ] Z6 ] Z5 NO PB-ATS on Shelf SHELF I.D. BLOCK Even Shelf ] Z6 ] Z5 PB-ATS on Shelf Note: These jumpers are located behind PBD-ATS or PBD24S MPG-ATS 6-27 Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...
  • Page 176 The shelf to which MPG-ATS: P1 (and P9 for redundant systems) connects, is numbered Shelf #0: P1 (MPG-ATS) connects to P3 on the PBD-ATS while P9 (MPG-ATS)  connects to P2 on the same PBD-ATS. 6-28 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...

  • Page 177: Even Shelf Cabling: Pbd-Ats To Mpg-Ats

    Left 32GC 32GC PBD-ATS 32GC Shelf #0 P1 1 Right PBD-ATS 32GC Shelf #4 Shelf #4 MPG-ATS Shelf #0 MPG-ATS To PBD-ATS To PBD-ATS Right control Left control (front view) (front view) 6-29 Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...

  • Page 178: Even Shelves 0 To 6: Mpg-Ats To Pbd-Ats Cabling Defining The Even Shelf Numbers

    Cabling Defining the Even Shelf Numbers Even shelf numbers are defined by the MPG-ATS Pn cable connection to the PBD-ATS as shown: Shelf #6 Shelf #4 MPG-ATS Shelf #2 Shelf #0 FC-19 cables 6-30 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...
  • Page 179 Even Shelf Numbers Even shelf numbers are To PBD-ATS To PBD-ATS To PBD-ATS defined by the MPG-ATS Pn cable connection to the PBD-ATS as shown: Shelf #14 Shelf #12 Shelf #10 Shelf #8 MPG-ATS 6-31 Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...
  • Page 180 Its shelf number is defined as the even shelf number +1. Therefore, the odd shelf connected to Shelf #0 is defined as Shelf #1, the odd shelf connected to Shelf #2 is defined as Shelf #3, etc. 6-32 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...

  • Page 181: Figure 6-24 Pbd24S To Pbd-Ats Cabling

    Figure 6-24 PBD24S to PBD-ATS cabling PBD24S FC16 flat cable PBD24S Odd shelf PBD-ATS Even shelf PBD-ATS MPG-ATS 6-33 Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...

  • Page 182: Digital Trunk Synchronization

    The Coral system uses two digital trunk cards as primary and secondary synchronization sources. The system synchronization signals are carried through two H-43 cables. The Coral FlexiCom 6000 system provides two additional synchronization connections, Third and External which are not used.

  • Page 183: Synchronization Cabling

    If one of these delicate pins is damaged, the other pair remains functional. Figure 6-25 Synchronization Cabling MPG-ATS (from slot 4) (from slot 4) SEC SYNC PRM SYNC H-43 cable MPG-ATS 6-35 Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...

  • Page 184: Rps/Pps Alarm Cabling

    If the white dots are not visible on the cable assembly, make certain that the color of the wire conductor at the top edge of the cable is the same at both ends. 6-36 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...

  • Page 185: Figure 6-26 Pps/Rps Alarm And Rps Inter-Shelf Cabling Detail

    Figure 6-26 PPS/RPS Alarm and RPS Inter-Shelf Cabling Detail LOWER MBS3 WHITE DOT UPPER MBS3 PBD24S TO MBC PBD-ATS LOWER MBS3 WHITE DOT UPPER MBS3 TO MBC MPG-ATS PBD-ATS 6-37 Coral FlexiCom 6000 Installation Manual Cabinet Descriptions...

  • Page 186: 10 Power Distribution

    The SGND terminal also must be connected to an approved earth ground through a separate path (separate wire). 6-38 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...

  • Page 187: 11 Configuration Options

    6-7. These tables define the cabinet structure, maximum ports and Time Slot definition for each type of Coral cabinet code. Each Coral FlexiCom 6000 system must include at least one main control cabinet with either 3 or 4 shelves, where the bottom shelf is always the control shelf.
  • Page 188 302220 None 3200 4096 322222 303220 303220 303220 None 4400 4096 423322 404420 None None None 2800 3584 423222 404220 404220 404220 None 6000 4096 420002 404220 404220 404220 404220 6400 4096 6-40 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...
  • Page 189 Hot Standby Configurations The Coral FlexiCom 6000 system can be configured as a stand alone system with only one set of control cards or a Hot Standby redundant system with two sets of control cards. The redundant system defines an Active and Standby side. The left or right side of the control shelf is defined as the Active, Standby or Inactive (Maintenance or Faulty) control side depending on the current system status.
  • Page 190 NOTES: 6-42 Cabinet Descriptions Coral FlexiCom 6000 Installation Manual...

  • Page 191: Power Supplies

    Chapter Power Supplies 7.1 PPS..................7-1 7.2 RPS ..................7-9 7.3 PS-ATS ................7-19 Coral FlexiCom 6000 Installation Manual...

  • Page 193: Pps

    PPS are designed to be paralleled with the outputs of a second PPS, offering load sharing of power supplies. Coral FlexiCom 6000 cabinets are factory wired to support load sharing. In cabinets with only 2 peripheral shelves, the power supply slots of both peripheral shelves are wired in parallel.
  • Page 194 Switching one PPS to OFF does not remove power from the peripheral shelf if an adjacent, paralleled PPS is switched ON. Paralleled power supplies must both be turned off to remove all power from both shelves. Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 195: Figure 7-1 Pps Front Panel Layout

    POWER SUPPLY INPUT Input fuse -48V PPS DC-DC converters INPUT Input fuse -48V PPS control & peripheral cards Power on green indicator Power switch Output voltage adjust Output test points +12V -12V -48V Coral FlexiCom 6000 Installation Manual Power Supplies...

  • Page 196: Circuit Description

    CONVERTER T.P. DGND -5V REG. POWER ON T.P. AGND L.E.D. -5V & -12V DC-DC CONVERTER -12V POWER SWITCH -12V REG. T.P. DGND -48V -48V IN -48V FILTER T.P. 48V RTN 48V RTN IN Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 197: Adjustment

    Table 7-1 PPS Voltage Nominal Minimum Maximum Adjust To Outputs +5VDC +5.15 +5.25 +5.20 +12VDC +12.25 +12.35 +12.30 –5VDC –5.05 –5.15 –5.10 –12VDC –11.40 –12.60 — –48VDC VIn–2.3 VIn–1.3 — Coral FlexiCom 6000 Installation Manual Power Supplies...

  • Page 198: Installation

    Turn on the PPS and RPS units only after powering the Main Control Shelf and verifying that the Main Control Shelf has initialized properly, otherwise the cards in the peripheral shelves/cages may not initialize. Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 199: Troubleshooting

    If the voltage drops after a particular card is inserted, that card is faulty, and should be replaced. Coral FlexiCom 6000 Installation Manual Power Supplies...

  • Page 200: Specifications

    +12V Adjust –5V Adjust Blown main or circuit fuse/breaker in the building electrical panel. Indicators: ...........Power ON/OFF (green) ALARM (red) (Protected by a fuse on the rear panel of the cage) Weight:..............1.4 kg Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 201: Rps

    RPS operation, an operating RPS in either peripheral shelf supplies both shelves. If both RPSs are operational, each RPS supplies energy only to the shelf in which it is installed.Coral FlexiCom 6000 cabinets are Coral FlexiCom 6000 Installation Manual...
  • Page 202 Switching one RPS to OFF does not remove power from the peripheral shelf if a shared RPS is switched ON. Shared power supplies must both be turned off to remove all power from both shelves. 7-10 Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 203: Figure 7-3 Rps Front Panel

    POWER SUPPLY INPUT INPUT BRV output -48VDC input fuse fuse Power Switch Power On Output indicator voltage adjust VOLTAGE ADJUST Test points OUTPUT 25 Hz 20 Hz Output 16 Hz frequency selector 7-11 Coral FlexiCom 6000 Installation Manual Power Supplies...
  • Page 204 (7 5V ) 7 Orange White (0 V ) 6 Brown Blue S P A R E F U S E S ( U N D E R S ID E ) 7-12 Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 205: Circuit Description

    FREQUENCY SELECTION (SWITCH ON FRONT PANEL) 105V T.P .1 POWER AMPLIFIER 1A S.B. FREQUENCY T.P .2 OSCILLATOR -48V POWER ON LED -48V MONITOR POWER CIRCUIT RELAY IN SWITCH 2A S.B. RELAY OUT +48V 7-13 Coral FlexiCom 6000 Installation Manual Power Supplies...

  • Page 206: Installation

    5. Turn the power switch ON. Turn on the PPS and RPS units only after powering the Main Control Shelf/Cage and verifying that it has initialized properly. Otherwise the cards in the peripheral shelves may not initialize. 7-14 Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 207: Adjustment

    RPS for each of the three output voltage selection taps. Never adjust the output voltage between 90VAC and 100VAC, or greater than 110VAC. Table 7-2 RPS Output Output Voltage Minimum Maximum Voltage Range Selection Tap 75VAC 85VAC 105VAC 7-15 Coral FlexiCom 6000 Installation Manual Power Supplies...

  • Page 208: Ringer Database Programming

    MAX_RING number of SLTs to ring simultaneously per shelf. See Chapter 6 — Ringers, of the Coral Program Interface & Database Reference Manual for details on the parameter definitions. 7-16 Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 209: Specifications

    Controls and Adjustments: ......ON/OFF Power Switch Output Voltage Adjust Output Ring Frequency Output Voltage Select Blown main or circuit fuse/breaker in the building electrical panel. (requires 30A/125V fuse on the cage rear panel) Weight:............3.0 kg 7-17 Coral FlexiCom 6000 Installation Manual Power Supplies...
  • Page 210 7-18 Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 211: Ps-Ats

    Top and bottom Four mounting screws (two at the top and two at the bottom) captive screws used to secure the unit to the cage. These screws also ground the unit to the cage. 7-19 Coral FlexiCom 6000 Installation Manual Power Supplies...

  • Page 212: Figure 7-6 Ps-Ats Front Panel

    PS-ATS units malfunctions. Alarms indicate the fault and inform the administrator via the various alarm indication facilities. The faulty PS-ATS unit can be replaced while the system is live and operating (Hot Standby), without the need to shutdown any part of the system. 7-20 Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 213: Circuit Description

    -48V In RTN Module Swap Circuit POWER +15V (Green LED) DC/DC +3.3V DC/DC Module -15V Module ±15V +3.3V +12V REG. +12V FAIL Enable (Red LED) -12V REG. Control & Alarm -12V Circuitry 7-21 Coral FlexiCom 6000 Installation Manual Power Supplies...

  • Page 214: Ps-Ats Orientation And Installation

    If more than considerable resistance is encountered, remove the power supply and examine the connectors for bent pins or interfering debris. 7-22 Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 215: Figure 7-8: Ps-Ats Orientation For Installation In Slots Ps2 And Ps3

    5. After power is supplied to the system, verify that the green Power indicator illuminates. Figure 7-8 PS-ATS Orientation for Installation in Slots PS2 and PS3 7-23 Coral FlexiCom 6000 Installation Manual Power Supplies...

  • Page 216: Figure 7-9 Ps-Ats Orientation For Installation In Slot Ps1

    Figure 7-9 PS-ATS Orientation for Installation in Slot PS1 7-24 Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 217: Troubleshooting

    Repeat this procedure for the other PS-ATS unit. If the green Power indicator lights but the red FAIL indicator does not light,  then the PS-ATS is functioning properly. Continue with the next step. 7-25 Coral FlexiCom 6000 Installation Manual Power Supplies...
  • Page 218 Cavity, (in the rear of the main cabinet at the top left-hand corner, see Figure 2-4) protecting the circuitry in the entire cabinet. Refer to Figure 7-10 Figure 7-11 for a DC wiring diagram of the Power Cabling and Fuse series. 7-26 Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 219: Figure 7-10 Coral Flexicom 6000 Control Shelf Dc Power Cabling Connections

    GND 3 GND 14 GND 2 GND 15 -48VDC -48VDC MPG-ATS +48VDC To PS fuses GND 1 GND 16 +48VDC FANS -48VDC Power to fans J5 J7 +48VDC Return to power supplies 7-27 Coral FlexiCom 6000 Installation Manual Power Supplies...

  • Page 220: Figure 7-11: Coral Flexicom 6000 Control Shelf Power Cabling And Fuses

    If none of those fuses has a red tip, then the F1 fuse inside the indicated PS1, 2, or 3 has blown and must be changed. 7-28 Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 221: Figure 7-12 Ps-Ats Side View

    7. Fasten the mounting screws to secure the PS-ATS into place. Removing one Power Supply Unit in a Hot Standby system does not affect call traffic in any way. Figure 7-12 PS-ATS Side Fuse View 10A 250V S.B. Front panel 7-29 Coral FlexiCom 6000 Installation Manual Power Supplies...

  • Page 222: Specifications

    Input:............–40VDC to –60VDC, 6A Max. Output: ............+5.2VDC, 20A Max. +3.3V, 20A Max. +12V, 1A Max. –12V, 0.5A Max. Indicators: ...........Power ON (green) ALARM/FAIL (red) Fuses: ............Input 10A/250V S.B. Controls and Adjustments: ......None 7-30 Power Supplies Coral FlexiCom 6000 Installation Manual...

  • Page 223: Common Control Cards

    Chapter Common Control Cards 8.1 Common Control Shelf ............8-1 8.2 MCP-ATS ................8-17 8.3 32GC ..................8-61 8.4 4/8XMM ................8-75 8.5 CLA-ATS ................8-81 8.6 PB-ATS ................8-99 8.7 PBD-ATS................8-107 8.8 PBD24S ................8-111 Coral FlexiCom 6000 Installation Manual...

  • Page 225: Common Control Shelf

    General Information ....................The Coral FlexiCom 6000 system provides a Hot Standby Dual Control System which offers a significant measure of system reliability and protection by assuring non-stop operations despite the possible failure of any control component. The redundant Coral FlexiCom 6000/R includes two complete sets of control hardware, each able to perform the control operations of the entire system.
  • Page 226 A single motherboard, the MBC-ATS, behind which the MPG-ATS resides, serves as the backplane for both sets of control systems. Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 227: Control Shelf Backplane Connections

    6. Push the MPG-ATS knobs toward the backplane studs to secure the connections. 7. Turn the knobs until they are tight. 8. Fasten the 12 mounting screws on the sides of the card. 9. Connect the required cables. Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 228: Figure 8-1 Control Shelf: Rear Backplane

    GND 10 GND 6 GND 11 GND 5 GND 12 GND 4 GND 13 +48VDC -48VDC GND 3 GND 14 GND 2 GND 15 -48VDC MPG-ATS +48VDC GND 1 GND 16 FANS Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 229: Figure 8-2 Mpg-Ats Interface Card Layout

    Figure 8-2 MPG-ATS Interface Card Layout Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 230: Control Card Assignments

    The Fan tray is located at the bottom of the Control Shelf and is described below in Fan Tray on page 8-15. Figure 8-3 Coral LEFT RIGHT Control Shelf - Front control control View Fuses 1 2 3 FAN-1 FAN-2 FAN-3 Fuse Fuse Fuse Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 231: Card Handling Procedures

    The coded keys prevent inserting the wrong card into a slot. Figure 8-4 illustrates the control shelf slot’s coded keys. Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 232: Figure 8-4: Control Card Slots And

    Never force the insertion of a Common Control card in a slot other than the one designated for that card. Irreparable damage may occur if a Common Control card is placed in an incorrect slot with power applied. Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 233: Inserting And Removing A Control Card

    If the card is to be inserted on the left side of the control cage, insert the  card upside down (the component side of the card is facing left). 5. Align the card top and bottom edge of the card on the slot guides. Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 234 Do not fasten the card to the cage with screws. A card that is fastened to the cage with screws might be damaged if the screws are not unfastened before card removal. 10. Connect any front panel cables, if necessary. 8-10 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 235: Figure 8-5 Inserting The Control Card

    Figure 8-5 Inserting the Ejector Control Card Latch Press latches. Push ejectors in direction of arrows. Insert card. At end of slot, push ejectors in direction of arrows. 8-11 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 236 Figure 8-6. Do not remove the card from its slot when the HD LED is flashing, indicating CFD or Hard Drive activity. 5. Remove the card from the cage or shelf. 8-12 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 237: Figure 8-6 Removing The Mcp-Ats Card

    Figure 8-6 Removing Ejector the MCP-ATS Card Latch Press latches. Push ejectors in direction of arrows Remove card 8-13 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 238: Lithium Backup Batteries

    There is a danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to requirements specified by the battery manufacturer and/or local regulatory agencies. 8-14 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 239: Fan Tray

    4. If none of the fuses are blown then one of the fans is not functioning (this may Replacing the Fan Tray, be obvious by simple inspection) and continue with below. Otherwise, the FAN FAULT repair terminates with the repaired fuse. 8-15 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 240: Figure 8-7 Control Shelf Fan Tray

    3. Fasten the screws, attaching the fan tray to the chassis. 4. Return Power to the system and check that all the fans are functioning properly. Figure 8-7 Control Shelf Fan Tray 0.5A/F/250V FAN-1 0.5A/F/250V FAN-2 0.5A/F/250V FAN-3 8-16 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 241: Mcp-Ats

    Main Processor Card General Description ....................The MCP-ATS is the main control processor for the Coral FlexiCom 6000 system. The MCP-ATS card supervises overall system operation. The MCP-ATS card contains the main control processor circuitry and utilizes a powerful Pentium microprocessor with PC architecture, which connects to the backplane with Compact PCI.

  • Page 242: Mcp-Ats Card Types

    Coral Versions Card Compatible Coral Software Versions 15.68.12 or higher Versions 15.00.00 - 15.68.11 Versions 14.67.83 - 14.99.99 Versions 14.00.00 - 14.67.82 Versions 12.00.00 - 12.99.99 Version 13 was never released 8-18 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 243: Cfd - Compact Flash Memory Disk

    Do not remove the CFD or MCP-ATS card from its slot when the HD LED is flashing, indicating CFD or Hard Drive activity. Removing a Control Card, 2. Remove the MCP-ATS card from the cage. See page 8-12. remove the CFD flash memory card. 8-19 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 244 SAU number that must correspond to the SAU device attached on the Software front panel of the 32GC on the same side of the MCP-ATS, see also Authorization Unit (SAU) on page 8-70. 8-20 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 245: Figure 8-8 Mcp-Ats (Tadiran Telecom) Layout

    BATTERY INSULATOR (PULL UP TO REMOVE) 1-2 CF Slave (CLA) 2-3 CF Master (MCP) REMOVE BEFORE Insert Backup Battery release button Reset Jumper P10 must be set to the MASTER (2-3) position. 8-21 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 246: Figure 8-9 Mcp-Ats (Tadiran Telecom) Layout With An Hard Disk

    Under hard disk REMOVE BEFORE USE 2-3 CF Master (MCP) (PULL UP TO REMOVE) Hard disk (optional) Insert release button Reset Jumper P10 must be set to the MASTER (2-3) position. 8-22 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 247: Figure 8-10 Mcp-Ats (Sbs-Ct7) Layout

    Figure 8-10 MCP-ATS (SBS-CT7) Layout Compact Insert Flash Disk (CFD) memory MCP-ATS (SBS CT7) 8-23 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 248: Figure 8-11 Mcp-Ats (Sbs-Ct9) Layout

    Figure 8-11 MCP-ATS (SBS-CT9) Layout Compact Insert Flash Disk (CFD) memory MCP-ATS (SBS CT9) 8-24 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 249: Figure 8-12 Mcp-Ats (Motorola Cpv 5350) Layout

    Figure 8-12 MCP-ATS (Motorola CPV 5350) Layout BATTERY DRAM Compact Flash Disk (CFD) memory Insert 8-25 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 250: Figure 8-13 Mcp-Ats (Motorola Cpv 5370) Layout

    Figure 8-13 MCP-ATS (Motorola CPV 5370) Layout Insert Compact Flash Disk (CFD) memory BATTERY 8-26 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 251: Front Panel Features

    ....................The following figures illustrate the front panels for the different MCP-ATS cards used in the Coral FlexiCom 6000 system. Note that the card is shown in its upright position for insertion on the right side of the control shelf.
  • Page 252 Two similar connections are for communication between the mouse and the mouse interface port. All four of these signals are CMOS compatible. The two remaining connections provide power for mouse and keyboard operation. 8-28 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 253 NOTE: If the system is not a Hot Standby system, all calls in progress during Reset, are disconnected. BIOS (Basic Input Output System) program which is permanently located in a computer's (MCP-ATS) memory and is activated at startup 8-29 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 254 CT7 has started. Before entering the OS boot sequence, the green LED is turned on. While in the OS, user software is free to use both LED's for their own purpose. 8-30 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 255 Hard Disk Drive (green) indicates hard drive activity on the primary IDE channel. Caution: Do not remove the card from its slot when this LED is flashing. Removing a Control Card, page 8-12. 8-31 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 256 DACVSS Video return no connection DDCDAT Display Data Channel data signal for DDC2 support HSYNC Horizontal synchronization VSYNC Vertical synchronization DDCCLK Display Data Channel clock signal for DDC2 support 8-32 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 257 Mouse (PS/2) Interface Pin Functions KBDDAT Data line for keyboard MDAT Data line for mouse Keyboard Ground KBDVCC Keyboard Power KBDCLK Clock for keyboard MCLK Clock for mouse CGND Common Ground 8-33 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 258: Figure 8-14 Mcp-Ats (Tadiran Telecom) Front Panel Upright Position

    Release latch Compact flash disk (CFD) slot Ethernet USB 2 USB 1 VGA (video) COM1 (KB0) Keyboard Reset button PWR indicator Hard disk indicator Hot insertion indicator ALARM indicator Release latch Handle 8-34 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 259: Figure 8-15 Mcp-Ats (Sbs-Ct7) Front Panel Upright Position

    Upright Position Push button to release lever (video) COM1 (KB0) Keyboard USB port EXT indicator (not used) PWR indicator STAT indicator Reset button Push button SBS CT7 to release lever Handle 8-35 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 260: Figure 8-16 Mcp-Ats (Sbs-Ct9) Front Panel Upright Position

    MCP-ATS (SBS-CT9) Front Panel Handle Upright Position Push button to release lever Ethernet 1 (not used) Ethernet 2 (not used) (video) COM1 (KB0) ST indicator Keyboard HS indicator Reset button Handle 8-36 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 261: Figure 8-17 Mcp-Ats (Motorola Cpv 5350) Front Panel Upright Position

    COM1 (KB0) COM2 (not used) Ethernet 1 (not used) Ethernet 2 (not used) USB port (not used) Keyboard Reset button ALARM indicator SPKR indicator HDD indicator PWR indicator CPV5350 MOTOROLA Handle 8-37 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 262: Figure 8-18 Mcp-Ats (Motorola Cpv 5370) Front Panel Upright Position

    Figure 8-18 MCP-ATS (Motorola CPV 5370) Front Panel Upright Handle Position CPV5370 Ethernet 1 (not used) Ethernet 2 (not used) COM1 (KB0) (video) Keyboard Reset button PWR/ALARM HDD indicator indicator MOTOROLA Handle 8-38 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 263: Verifying The Bios Settings

    Go to Partners login, type your username and password. Click Enter. The Main Partners page is displayed. Go to Support. Refer to the list of card models supplied for the MCP-ATS and execute its corresponding BIOS Setup procedure. 8-39 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 264 BIOS Settings for the CP-ATS Tadiran Telecom The card BIOS settings are factory-configured to match the MCP-ATS card requirements. Use the following procedure to verify the correct BIOS settings for the MCP-ATS card model: Tadiran Telecom. 1. Connect a video terminal and keyboard to the front panel of the card.
  • Page 265 Reset button on the MCP-ATS front panel. Messages for a Properly 10. Check to see that the Coral initializes properly, see Loading Active Side on page 3-12 Messages for a Properly Loading Standby Side on page 3-14. 8-41 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 266 [hh/mm/ss] Floppy Drive A: Not Installed Floppy Drive B: Not Installed Type Pri Master Auto Pri Slave Not Installed Sec Master Auto Sec Slave Not Installed Boot Sector Virus Protection Disabled 8-42 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 267 640x480 T16 Stretch Text Modes Stretch Graphics Mode Symbios SCSI BIOS Enabled Advanced Chip Setup BIOS Option Value USB Function Enabled USB KB/Mouse Legacy Support Auto Port 64/60 Emulation Disabled SERR# Enabled 8-43 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 268 PCI Upstream Window 1 Type Disabled PCI Upstream Window 1 Size PCI Upstream Window 2 Page Size Disabled VMEbus System Controller State Auto VMEbus Access Window Size 512MB Spread Spectrum Clock Modulation 8-44 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 269 PCI Latency Timer (PCI Clocks) PCI VGA Palette Snoop Disabled DMA Channel 0 DMA Channel 1 DMA Channel 3 DMA Channel 5 DMA Channel 6 DMA Channel 7 IRQ3 PCI/PnP IRQ4 PCI/PnP IRQ5 PCI/PnP 8-45 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 270 Auto OnBoard IDE Both Compact PCI sideband INTP IRQ Disabled OnBoard IMPI controller OnBoard High-Res Timer IRQ Disabled Swap Floppy Drives OnBoard Ethernet #1 connector Front OnBoard Ethernet #2 connector Front 8-46 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 271 Reset button on the MCP-ATS front panel. Messages for a Properly 15. Check to see that the Coral initializes properly, see Loading Active Side on page 3-12 Messages for a Properly Loading Standby Side on page 3-14. 8-47 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 272 4. Use your keyboard’s right arrow to select the Exit tab. 5. Use the up/down arrows to select: Load Optimal Defaults and press Enter. 6. Select OK to load optimal defaults. 8-48 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 273 CFD flash disk. Check to see that it is installed properly. 8. After verifying these changes, Enter the Exit tab and save your changes. 9. Select Save Changes and Exit and press OK to save. 8-49 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 274 Reset button on the MCP-ATS front panel. Messages for a Properly 9. Check to see that the Coral initializes properly, see Loading Active Side on page 3-12 Messages for a Properly Loading Standby Side on page 3-14. 8-50 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 275 PCI IRQ Line 1 Auto Select PCI IRQ Line 2 Auto Select PCI IRQ Line 3 Auto Select PCI IRQ Line 4 Auto Select I/O Device Configuration Serial Port A ENABLE Base I/O address 8-51 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 276 Other parameters are Not Applicable SECURITY SCREEN PARAMETERS Parameter Value User Password is [CLEAR] Supervisor Password is [CLEAR] Set User Password ENTER Set Supervisor Password ENTER Password On Boot DISABLE STATUS Not Changeable N/A 8-52 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 277 Boot Device Priority +Hard Drive Bootable Add-in Cards Compact Flash Disk (Manufacturer Name) Removable Device ATAPI CD-ROM DRIVE Legacy Network Boot Hard Drive Compact Flash Disk (Manufacturer Name) Bootable Add-in Cards 8-53 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 278 Type Auto Cylinders Heads Sectors Maximum Capacity 48Mb Multi-Sector Transfers Disabled LBA Mode Control Disabled 32 Bit I/O Disabled Transfer Mode Fast PIO 1 SMART Monitoring Disabled Ultra DMA Mode Disabled 8-54 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 279 Base I/O Address Interrupt IRQ 4 Serial Port B Enabled Base I/O Address Interrupt IRQ3 Parallel Port Enabled Mode Bi-Directional Base I/O Address Interrupt IRQ7 Floppy disk controller Enabled Base I/O Address Primary 8-55 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 280 Boot Screen BIOS Option Value Floppy Check Disabled QuickBoot Mode Enabled Summary Screen Disabled SETUP Prompt Enabled NumLock Auto Hard Drive Compact Flash Disk (Manufacturer Name) Removable Devices ATAPI CD-ROM Drive 8-56 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 281 ECC Memory Config Disabled Advanced Screen BIOS Option Value Plug and Play O/S Reset Configuration Data Legacy USB Support Enabled Floppy Configuration IDE Configuration I/O Configuration PCI Configuration Remote Console Embedded Flash 8-57 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 282 P/S Mouse Auto Detect Serial Port A Enabled Base I/O Address Interrupt IRQ4 Serial Port B Enabled Base I/O Address Interrupt IRQ3 Parallel Port Enabled Mode Bi-Directional Base I/O Address Interrupt IRQ7 8-58 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 283 Quick Boot Enabled Summary Screen Disabled SETUP Prompt Disabled NumLock Auto Boot Retry Enabled Boot Device Priority Hard Drive Compact Flash Disk (Manufacturer Name) Bootable Add-in Cards Removable Devices ATAPI CD-ROM Drive 8-59 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 284 Reset button on the MCP-ATS front panel. Messages for a Properly 16. Check to see that the Coral initializes properly, see Loading Active Side on page 3-12 Messages for a Properly Loading Standby Side on page 3-14. 8-60 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 285: 32Gc

    General Description ....................The 32GC card serves as the communication link in the Coral FlexiCom 6000 system, between the MCP-ATS and the PB-ATS cards (located in peripheral shelves), or the FLMS cards (located in FlexLITE remote peripheral shelves); via the MPG-ATS located at the motherboard rear backplane.
  • Page 286 Lights when this system side in Standby mode M (red) Indicator Lights when this system side is in Maintenance mode F (red) Indicator Lights when the this system side is in Faulty mode 8-62 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 287 A, B and C, which aid in the piggyback installation of the XMM card. A Lithium battery resides on the side panel as well. The battery insulator must be removed before card installation. 8-63 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 288: Figure 8-20 32Gc Front Panel Upright Position

    - Faulty (Red) All dip switches set to the right CLA-ATS Run Indicator SAU Device Interface Upper XMM Indicators Not Used CLA-ATS supported by Lower XMM Indicator 32GC Reset CLA-ATS button 8-64 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 289: Figure 8-21 32Gc Card Layout

    Figure 8-21 32GC Card Layout Tones, DTME, MFC PROM Card Software Card Software 100 pin female connector 32GC BATTERY INSULATOR REMOVE BEFORE (PULL DOWN TO REMOVE) 8-65 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 290: Lithium Battery Handling Procedures

    32GC card automatically identifies whether the Peripheral Shelves units require only 128 of the entire 512 time slots or the entire 512 time slots per Unit. 128 - Coral FlexiCom 5000 Peripheral shelves (field upgrades)  512 - Coral FlexiCom 6000 Peripheral shelves  8-66 Common Control Cards...

  • Page 291: Figure 8-22 Coral System Dual Control Highway Structure

    Figure 8-22 Coral system Dual Control Highway Structure Mirrored Memory 32GC 32GC Snooping STANDBY ACTIVE Side Side 8-67 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 292: Figure 8-23 Coral System Pcm Highway Distribution For 32Gc

    Peripheral Shelves 8, 9 512 time slots PB-ATS Peripheral Shelves 10, 11 512 time slots PB-ATS Peripheral Shelves 12, 13 512 time slots PB-ATS Peripheral Shelves 14, 15 512 time slots 8-68 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 293: Circuit Description

    2K ports and any other 2K ports, on any of the 16 peripheral shelves, for a max of 2K calls. This switching matrix allows for a Constant Frame Delay operation mode. 8-69 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 294: Software Authorization Unit (Sau)

    Relevant system messages appear on the PI, warning that the system will not operate without the proper SAU. Replacing a 32GC card requires removing the SAU from the old card and installing it on the replaced 32GC card. 8-70 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 295 SAU serial number on the corresponding CFD card label, inserted in the MCP-ATS on the same side of the control shelf. Otherwise, the system will automatically shut down after 14 days. 8-71 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 296 If both system sides have any of these Alarm messages, then the entire Coral system will only function for a maximum of 14 days. 8-72 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 297: Inserting A 32Gc Card

    2. The SAU device and its corresponding CFD memory card are shipped in their own coral software box. Two separate coral software boxes are provided for redundant Coral FlexiCom 6000/R HSB systems: one for the right side and on e for the left side of the control shelf.

  • Page 298: Flexlite Remote Shelves

    FlexLITE Remote Shelves ....................The Coral FlexiCom 6000 has the ability to site peripheral shelves at a maximum distance of 35 km. (21 miles), from the main Coral cabinet using fiber-optic cables. The remote shelves can be:  FlexLITE Coral FlexiCom 400 cabinet ...

  • Page 299: 4/8Xmm

    4/8XMM includes 3V lithium battery backup for power protection. The 4/8XMM card is installed as a piggyback card onto a memory interface connector on the 32GC and does not occupy its own card slot within the Coral FlexiCom 6000 control shelf.
  • Page 300 8XMM card. The holes, A, B and C, are provided for the connection screws, on both cards. They should be aligned exactly when attaching the XMM onto the 32GC, see To attach the 4/8XMM onto a 32GC card: on page 8-78. 8-76 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 301: Figure 8-25 4/8Xmm Card Layout

    100 pin Dip switch female (not used) 1 2 3 4 connector CLA Run Indicator Exist Indicator Reset Rear Side (Bottom View) 100 pin male connector BATTERY INSULATOR (PULL DOWN TO REMOVE) 8-77 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 302 8-26. 6. Fasten one M2.5 screw through mounting hole A of the 4/8XMM card. 7. The LEDS from the XMM card should be visible from the front panel of the 32GC. 8-78 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 303: Figure 8-26: Xmm Installed On 32Gc

    Figure 8-26 installed on 32GC 32GC 8 XMM M3 Interface screws with Hex Spacers below M2.5 Interface 1 2 3 4 screw Component side (Top View) 8-79 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 304: Specifications

    Voltage ........3.0VDC Nom. Capacity ........250mAH Width........0.118 in. (3 mm) Diameter........0.965 in. (24.5 mm) NEDA Equivalent ....5011L Coral Components Discontinuation Announcement: 8XMM cards replace the discontinued 4XMM cards, which are no longer produced. 8-80 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 305: Cla-Ats

    Standby/Duplicated mode, not offering CTI Hot Standby operation. Therefore, during common control swaps, the CTI application restarts without maintaining its current calls and functions and will disconnect active CTI calls. 8-81 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 306: Card Description

    The 64MB (or more) Compact Flash memory Disk (CFD) contains the card’s software and programming code. The CLA-ATS card also contains an NMI/watchdog circuit, providing a reset signal to the Core Module should it detect a failure in the software cycle. 8-82 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 307: Jumper Settings

    Normal Mode - Off W7- Onboard Video Enabled - Off W9, W10 COM2 Terminations RS-422/485 modes only Without Termination resistors - off W11- Compact Flash Slave - Off J7 - Fan Header 8-83 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 308: Figure 8-27 Cla-Ats Front Panel - Upright Position

    Power OK Indicator Reset button COM 1 RS-232 Port: Not Used Network Interface Ethernet RJ-45 connector Keyboard/ mouse Ready To Swap indicator Injector/ejector microswitch (red) cPCI-MXP Bottom handle CLA-ATS (teknor cPCI-MXP) 8-84 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 309: Figure 8-28 Cla-Ats Card Layout

    2 off disabled Injector/ejector microswitch BIOS Onboard Video W9 W10 COM2 Terminations On Disabled On On With termination resistors Off Enabled Off Off Without termination resistors CLA-ATS (teknor cPCI-MXP) 8-85 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 310: Figure 8-29 Cla-Ats Card With Cfd Drive Removed

    CFD Drive Rear View removed CFD Drive CFD Drive Connector CLA-ATS (teknor cPCI-MXP) Lithium Backup Battery Lithium Backup Batteries, For a full description of control card lithium batteries, refer to page 8-14. 8-86 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 311: Figure 8-30 Cla-Ats- Functional Block Diagram

    A CLA-ATS functional block diagram is shown in Figure 8-30. Figure 8-30 CLA-ATS- Functional Block Diagram 4/8XMM MCP-ATS Ethernet CPCI CPCI Main Cable 32GC To LAN CLA-ATS Control Group Processor Controller Card Common Control 8-87 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 312: Inserting The Cla-Ats Card

    CLA-ATS has initialized properly: CLA is Active Refer to Chapter 27 of the relevant Program Interface & Database Reference Manual for other CLA-ATS messages indicating a faulty CLA initialization along with technical recommendations. 8-88 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 313: Installing A Cfd In The Teknor Cpci-Mxp Cla-Ats Card

    Insert the new CFD. The CFD is inserted with its label face up. The CFD cannot be inserted upside down. Reattach the drive to its connector on the CLA-ATS card, see Figure 8-29. Fasten the screws to secure the CFD in its place. 8-89 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 314: Bios Settings

    Full Screen LOGO Show Disabled Boot from LAN First Disabled Raid Card Boot First Disabled Boot Sequence C,A,SCSI Swap Floppy Drive Disabled Boot Up Floppy Seek Disabled Drive A Boot Permit Enabled 8-90 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 315 Memory Hole at 15M-16M Disabled Video BIOS Cacheable Enabled Video RAM Cacheable Enabled 8 Bit I/O Recovery Time 16 Bit I/O Recovery Time PCI/VGA Palette Snoop Disabled Passive Release Enabled Delayed Transaction Disabled 8-91 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 316 IDE HDD Block Made Enabled Ether Controller Enabled USB Key Board Support PS/2 mouse control Auto Onboard FDC Controller Enabled Onboard Serial Port 1 Auto Onboard Serial Port 2 Auto Serial port mode RS-232 8-92 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 317 HEADPRECOMP LAND2SECTOR MODE 2 (Y) 65535 32 Normal 13. Return to the main screen and choose the SAVE & EXIT SETUP option. 14. Type Y to SAVE to CMOS and EXIT. 8-93 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 318: Network Connections

    The installation of a CLA-ATS card to a Coral system has considerable impact on the system database. For further information, refer to Chapter 27 of the relevant Program Interface and Database Reference Manual. 8-94 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 319: Applications

    The CLA-ATS should be accompanied by the appropriate software application. Contact your manufacturer for the required CTI application and/or price list. See Chapter 2 in the Coral FlexiCom & Coral IPx Product Description, for more details. 8-95 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 320: Figure 8-31 Coralink Application Telephony Server

    Application Telephony 6000 TCP/IP Server CTI Clients CoraLINK CoraLINK Interface Interface RJ-45 Server Server Any Telephony Server (e.g. FlexCT server, CallPath, CT Connect, TSAPI, up to 8 connections). Computers with CTI applications 8-96 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 321: Specifications

    Access Protocol: .........ITU X.217/X.227 (ACSE), X.219/X.229 (ROSE) Network Type: ..........IEEE 802.3 Ethernet Network Topology:........10/100Base-Tx Ethernet Network Interface Connector: ....RJ-45 Network Transport Protocol: ......TCP/IP D slot............ATA Type Coral Common Control ......Coral FlexiCom 6000/6000R 8-97 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 322 NOTES: 8-98 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 323: Pb-Ats

    PB-ATS cards in slots# 1 and 2. A PBD-ATS card connects each pair of PB-ATS cards, in which a connection exists between an even and an odd shelf, and between each 32GC card and a PBD-ATS card. 8-99 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 324: Figure 8-32 32Gc And Peripheral Shelf System Block Diagram

    Active 32GC. Recognizing Time Slot Configurations Each PB-ATS supports 128 or 512 PCM time slots, depending on the Peripheral Shelf Unit backplane type. The 32GC card automatically identifies whether the Peripheral 8-100 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 325 The PB-ATS card defines its time slot operation automatically at 128 time slots or at 512 time slots according to the type of backplane installed on the peripheral shelf unit. The Coral FlexiCom 6000 incorporates only backplanes which use all 512 time slots. Peripheral shelves from upgraded Coral FlexiCom 5000 systems, may use backplanes that accept only 128 time slots.
  • Page 326 1 and 2. The other peripheral cards have the rounded corner on the top. When upgrading older peripheral shelves to a Coral FlexiCom 6000, the upgrade kit includes a replacement track for slot 2.

  • Page 327: Circuit Description

    Active. The Active PB-ATS may be switched via the UNITS ( Sysgen,5 ) branch in the PI, see Chapter 4 of the relevant Program Interface & Database Reference Manual. Figure 8-33 illustrates the PB-ATS circuits in block diagram form. 8-103 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 328: Figure 8-33 Pb-Ats Circuit Block Diagram

    PCM Tx 1-4 8.192 MHz 4.096 MHz CLK A/B Active/Standby Selector 8.192 MHz Right HDLC Rx + Tx CNR A/B 32GC HDLC Selector Left HDLC Rx + Tx CNT A/B 32GC 8-104 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 329: Front Panel Indicators

    FlexiCom 6000 backplane supporting 512 time slots and indicates that this Peripheral Shelf Unit is using 512 time slots. Alarm Faults are reported to the PI Terminal even if no indication is displayed on the panel itself. 8-105 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 330: Figure 8-34 Pb-Ats Front Panel

    Figure 8-34 PB-ATS Front Panel PB-ATS PB-ATS Active Indicator- Alarm Indicator (Red) ALARM (Green) 128 Time Slot Indicator (Green) 512 Time Slot Indicator 8-106 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 331: Pbd-Ats

    Common Control shelf. The PB-ATS card communications are carried via the PBD-ATS card, connected to the backplane behind it, on the rear side of slot 1 and 2. Figure 8-35 demonstrates this relationship. 8-107 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 332: Figure 8-35 32Gc - Pb-Ats Card Communications Via Pbd-Ats

    Figure 8-35 32GC - PB-ATS Card Communications via PBD-ATS PBD24S Odd Shelf FC16 Cable Backplane PBD-ATS PB-ATS PB-ATS FC19 Cable FC19 Cable MPG-ATS Right Left 32GC 32GC Even Shelf H-41 Cable Backplane 8-108 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 333: Card Description

    3. Remove screws on the top and bottom of the PBD-ATS. 4. Grasp the levers and push them outward to eject the card. 5. Verify that the shrouds between the backplane and the PBD-ATS card are in place on the backplane. 8-109 Coral FlexiCom 6000 Installation Manual Common Control Cards...

  • Page 334: Card Layout

    9. Return power to the Coral System. Figure 8-36 PBD-ATS Card Layout Front View Back View For upgrading older low density peripheral shelves with the PBD-ATS, see the instructions provided in the upgrade kit. 8-110 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 335: Pbd24S

    1, of the odd numbered peripheral shelves, where the PB-ATS card(s) are not installed. The Coral FlexiCom 6000 system main processor, MCP-ATS, converses through the 32GC with the peripheral devices via the PB-ATS card(s). The 32GC card communications are carried out via the MPG-ATS card located on the backplane behind it, on the rear side of the Common Control shelf.
  • Page 336 One 50-pin connector, P1, used to connect the PBD24S to its associated  PBD-ATS card via an FC16 (100cm) or FC18 (50cm discontinued) flat cable. PBD24S to PBD-ATS cabling, page 6-33. J2 is not used.  J3 is not used.  8-112 Common Control Cards Coral FlexiCom 6000 Installation Manual...

  • Page 337: Figure 8-37: Pbd24S Front And Back Card Layout

    N o t Front and Back Card C o n n e c t e d Layout N o t C o n n e c t e d Front View Back View 8-113 Coral FlexiCom 6000 Installation Manual Common Control Cards...
  • Page 338 NOTES: 8-114 Common Control Cards Coral FlexiCom 6000 Installation Manual...
  • Page 340 International Headquarters Tadiran Telecom Ltd. 18 Hasivim Street P.O.Box 7607 Petach Tikva 49170 Israel Tel. +972-3-9262000, Fax. +972-3-9262310 USA Headquarters Tadiran Telecom, Inc. 4 Tri Harbor Court Port Washington, NY 11050 Tel. +1-516-632-7200, Fax. +1-516-632-7210 http://www.tadirantele.com C o r a l...

Table of Contents
