To insert CFD Flash on
MCP-ATS
Connect video terminal
Enter BIOS
Coral FlexiCom 6000 Installation Manual
BIOS Settings for the SBS-CT7
There are two different models for the SBS-CT7 card. The procedure described
immediately below is for most SBS-CT7 models.
For the SBS-CT7 P70500470CW24 V4.D, see

P70500470CW24 V4.D on page
1. Remove the MCP-ATS card from its slot (see
page 8-12).
2. Insert the CFD if not already inserted on the card's side panel.
3. Install the card into the slot labeled MCP-ATS in the Control Cage (see
Inserting a Control Card, page
4. Connect a video terminal and keyboard to the card's front panel.
5. Turn on the main Power to the Coral system.
6. Press the Keyboard F2 or Delete key while the card is loading.
7. Ensure that the BIOS settings match the values displayed in the Tables listed
BIOS Values for SBS-CT7
in
8. After verifying the correct values, choose the SAVE CURRENT SETTINGS
AND OPTIONS option and type Y to save the BIOS updates.
9. Remove the Keyboard and video connections and re initialize the Coral system
by pressing the Reset button on the MCP-ATS front panel.
10. Check to see that the Coral initializes properly, see
Loading Active Side on page 3-12
on page 3-14.
BIOS Settings for the SBS-CT7
8-47.
Removing a Control Card,
8-9).
below.
Messages for a Properly Loading Standby Side
or
Messages for a Properly
8-41
Common Control Cards
