Figure 8-6
Removing
the MCP-ATS Card
Coral FlexiCom 6000 Installation Manual
Ejector
Latch
Press
1
latches.
Push ejectors
2
in direction
of arrows
Remove
3
card
Common Control Cards
8-13
