Figure 2-18 Pbd-Ats Ground Connections - Tadiran Telecom Coral FlexiCom 6000 Installation Procedure And Hardware Reference Manual

Hide thumbs
Table of Contents

Advertisement

Figure 2-18
PBD-ATS
Ground Connections
Coral FlexiCom 6000 Installation Manual
FC-19 cable
to
MPG-ATS P9
GND2
Ground
cables
GND3
FC-19 cable
to
MPG-ATS P1
PBD-ATS
P1
P2
P3
1
P6
4
1
P7
4
Hardware Installation Procedure
2-47
