4-22
Software Installation Procedure
9. Connect the corresponding SAU device to the front panel of the 32GC on the
same side of the Control Shelf.
For HSB systems, repeat this step for both SAU devices.
The generic feature software contained in the CFD is coded to function with one unique
SAU, which must be installed on the front panel of the CORRESPONDING 32GC card.
10. Return Power to the system, by first supplying the main power to the cabinet
and then turning on the peripheral power supply units (PPS and RPSs) in each
of the peripheral shelves.
11. Verify that the Coral is loaded properly by viewing the
message with the new Version number, see
Active Side beginning on page 3-12
Side beginning on page 3-14
Verify that no SAU fault messages appear during the loading process, see
System Faults on page
The Coral system automatically ceases call processing after 14 days for any of the
following reasons:

The SAU serial number does not match the corresponding CFD SAU serial number.

The Coral generic version contained in the CFD is higher than is authorized by the SAU.

An SAU is removed from the 32GC front panel.
Relevant system messages appear on the PI automatically warning that the system will
not operate without the proper SAU.
12. The new CFD card(s) do not include a backup of the current database. To
make a backup of the database, perform the procedure described in
System Database on page
13. In order for the Coral FlexiCom 6000/R system to function as a Hot Standby
system, both MCP-ATSs must have the same Coral generic version loaded on
their CFD cards. Otherwise, the system is not in Hot Standby mode and
automatically reverts to a single sided system, where one side is Active, while
the other side is Faulty and does not operate.
Messages for a Properly Loading
Messages for a Properly Loading Standby
and
when the Standby side exists.
8-72.
4-4.
CCS on the air
Saving the
Coral FlexiCom 6000 Installation Manual
SAU
