Figure 2-19: Pi Db9 Terminal To Kb0 Connection - Tadiran Telecom Coral FlexiCom 6000 Installation Procedure And Hardware Reference Manual

Figure 2-19 PI DB9
Terminal to KB0
Connection
Figure 2-20 PI DB25
Terminal to KB0
Connection
Coral FlexiCom 6000 Installation Manual
5
9
4
3
2
6
1
KB0
PROGRAMMING PORT
(USE FEMALE CABLE 9 PIN CONNECTOR)
5 - SIGNAL GROUND
4 - DATA TERMINAL READY
3 - TRANSMIT DATA
2 - RECEIVE DATA
1
KB0
PROGRAMMING PORT
(USE FEMALE CABLE 9 PIN CONNECTOR)
SIGNAL GROUND - 5
DATA TERMINAL READY - 4
TRANSMIT DATA - 3
RECEIVE DATA - 2
CARRIER DETECT - 1
9 PIN PC ASYNC. SERIAL PORT
(USE FEMALE CABLE CONNECTOR)
13
SIGNAL GROUND - 7
DATA SET READY - 6
CLEAR TO SEND - 5
REQUEST TO SEND - 4
RECEIVE DATA - 3
TRANSMIT DATA - 2
1
PC Async. Serial Port
or Async.Data Terminal
(USE FEMALE CABLE CONNECTOR)
Hardware Installation Procedure
9
6
25
14
2-51
